- Page 1 LINEA 6222 ™ CONSOLE DESK INSTRUCTION MANUAL DESIGN MATTHEW WEATHERLY...
- Page 3 Congratulations on the purchase of your Linea Console Desk 6222 from BDI. Your desk has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information that will ensure that you get the most out of your product.
- Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for the assembly of this product.
- Page 5 HARDWARE AND COMPONENTS PART # PART # DESCRIPTION Leg Frame – Left DESCRIPTION Leg Frame – Right QUANTITY QUANTITY PART # PART # DESCRIPTION DESCRIPTION Drawer Liner Wire Management Extrusion QUANTITY QUANTITY NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 5...
- Page 6 (C1) Desktop Assembly back rail. Attach using 2 (H1) M6 Screws and partially H1-SCREW tighten with (T1) Hex Wrench. NOTE: Do not tighten until all screws are in place. Open drawer partway Desk Assembly back rail 6 | BDIUSA.COM LINEA 6222...
- Page 7 STEP 2. ATTACH RIGHT LEG FRAME ASSEMBLY Slide metal tab of (C3) Right Leg Frame into the PART/DESCRIPTION opposite end of (C1) Desktop Assembly back rail as shown. T1-HEX WRENCH Attach using 2 (H1) M6 Screws and partially tighten with (T1) Hex Wrench. NOTE: Do not tighten until all screws are in place.
- Page 8 Using 6 (H2) Screws, fasten the legs to the PART/DESCRIPTION (C1) Desktop Assembly threaded holes on the underside of the desk. Tighten with (T1) Hex Wrench. T1-HEX WRENCH You may now tighten all screws. H2-SCREW 8 | BDIUSA.COM LINEA 6222...
- Page 9 2 PERSON TASK STEP 4. INSERT DRAWER LINER ASSEMBLY With help from another person, carefully position your Linea Console desk onto its base, making sure the drawer remains closed. Once the desk is upright, open the drawer and install the (C4) Drawer Liner. STEP 5.
-
Page 10: Fine Tuning
FINE TUNING LEVEL DESK Your Linea Console is equipped with built-in levelers. Dial down one or more levelers (by hand) until you attain a level stance. Dial down 10 | BDIUSA.COM LINEA 6222... -
Page 11: Care And Maintenance
While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please take care to avoid positioning your BDI cabinet in any area with extensive direct sunlight. -
Page 12: Warranty
WARRANTY BDI warrants to the original purchaser that for the below-stated warranty term, BDI will repair or replace any product, part, or component covered by this warranty that fails under normal use as a result of a defect in material or workmanship. BDI will repair or replace the aforementioned product, part or component with a comparable product, part or component.
