Chapter
11 Modifying the General Settings for Navigation Functions
1 Touch [Settings] in the navigation
menu, then touch [Regional Settings].
2 Touch [km / mile] to change the setting.
Each time you touch the key changes that set-
ting.
[mile] (default):
Show distance in miles.
[Mile&Yard]:
Show distance in miles and yards.
[km]:
Show distance in kilometers.
Changing the virtual speed of
the vehicle
When calculating the expected time of arrival
and the number of hours to the destination,
set the average speed for the freeway or ordin-
ary roads using [+] and [-].
1 Touch [Settings] in the navigation
menu, then touch [Regional Settings].
2 Touch [Average Speed].
3 Touch [+] or [-] to set the speed.
p The estimated time of arrival is not necessa-
rily estimated based on this speed value.
Checking the Setting
Related with Hardware
The hardware status, including the driving sta-
tus of a vehicle, positioning status by satellite,
learning status of the 3D sensor, and cable
connection status, can be checked.
90
En
Checking the connections of
leads and installation positions
Check that leads are properly connected be-
tween the navigation system and the vehicle.
Please also check whether they are connected
in the correct positions.
1 Touch [Settings] in the navigation
menu, then touch [Hardware].
2 Touch [Connection Status].
The "Connection Status" screen appears.
1 Speed Pulse
The Speed Pulse value detected by the navi-
gation system is shown. [0] is shown while
the vehicle is stationary.
2 GPS Antenna
Indicates the connection status of the GPS
antenna, the reception sensitivity, and from
how many satellites the signal is received. If
the signal is received correctly, [OK] is dis-
played. If reception is poor, [NOK] appears.
In such case, please change the installation
position of the GPS antenna.
3 Phone Connection Status
Indicates the connection status of the Blue-
tooth unit (sold separately) and the signal
strength between the Bluetooth unit and
the cellular phone. If the Bluetooth unit is
connected correctly, [OK] is displayed.
[NOK] appears when the Bluetooth unit is
not connected or incorrectly connected.
4 Installation Position
1
2
3
4
5
6
7
8
