- Page 1 Grinder Tweaky, touch-sensitive discrete distortion device Contents of this document are ©2024 Pedal Parts Ltd. No reproduction permitted without the express written permission of Pedal Parts Ltd. All rights reserved.
- Page 2 Before you dig in, ensure you download and read the General Build Guide. It contains all the information you need for a successful outcome.
- Page 3 Schematic + BOM 100p 2N5457* Q2-6 2N3904 470p 1N5817 220n BASS 100KA 100K 220p GAIN 2u2 elec 10KB 10u elec TREB 100KA 22u elec 100KA 22u elec WEIGHT 100KC 100K 1u elec 470K 1u elec BIAS 10K trimmer 100u elec 560R *Original is 2N5103.
- Page 5 Snap the small metal tag off the pots so they can be mounted flush in the box. You should solder all other board-mounted components before you solder the pots. Once they’re in place you’ll have no access to much of the board. BIASING Adjust the trimmer while measuring the voltage on the T pad.
-
Page 6: Drilling Template
10mm 35mm This template is a rough guide only. You should ensure correct marking of your enclosure before drilling. You use this template at your own risk. Pedal Parts Ltd can accept no responsibility for incorrect drilling of enclosures. FuzzDog.co.uk...
