- Page 1 Fume Hoods FH-L-Series USER MANUAL PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION Hagavish st. Israel 58817 Tel: 972 3 5595252, Fax: 972 3 5594529 mrc@mrclab.com MRC.4.25...
-
Page 2: Preface
Preface Dear Users Thank you very much for purchasing our FH-L-Series Fume Hood Please read the “Operating Instructions” and “Warranty” before operating this unit to assure proper operation. After reading these documents, be sure to store them securely together with the “Warranty” within touch for future reference. -
Page 3: Table Of Contents
Content Preface ..............................2 Content ..............................3 1.Unpacking, Installation and Debugging ..................4 1.1 Unpacking ..........................4 1.2 Unpacking of Base Cabinet ...................... 6 1.3 Accessories Checking ....................... 7 1.4 Environment requirements ......................7 1.5 Installation ..........................8 1.6 Inspection after Installation ...................... 9 2.User Instructions ..........................9 2.1Functions ............................9 2.1.1 Product concept .......................9... -
Page 4: Unpacking, Installation And Debugging
1.Unpacking, Installation and Debugging Please firstly check if packing box is in good condition. If the packing box is damaged, please take photos. 1.1 Unpacking 1) Box 1 Method 1: Use M8 Wrench to unpack Picture 1... - Page 5 2) Method 2: Use M8 Wrench to unpack Picture 2 Rapid unpacking diagram (Picture 3). Disassemble the screws shown in the below Picture, then move the wooden pieces to right and left. Picture 3 box2 Quick unpacking Use ordinary scissors to cut the packing tape, remove the top cover of the paper packaging, and move the paper packaging frame upwards.
-
Page 6: Unpacking Of Base Cabinet
Picture 4 1.2 Unpacking of Base Cabinet Choose a proper unpacking method according to the actual situation. 1.2.1For wooden box Please refer to the main body unpacking method (of wooden box) in the previous pages, use M8 electric drill or M8 wrench to remove the screws and unpack the box. Picture 5 1.2.2For cartoon box Please refer to the main body unpacking method (of carton box) in the previous pages, use scissor to... -
Page 7: Accessories Checking
Picture 6 1.3 Accessories Checking Main body box: Items Quantity Main body 1 unit User manual 1 pc Certification of quality 1 pc Inspection report 1 pc Fuse (5A) 1 pc Fuse (10A) 1 pc power cable 1 pc Allen wrench 1 pc Base stand 1 unit... -
Page 8: Installation
a) Electrical parameters: consistent with the rated voltage and rated frequency of the Fume Hood (See 2.1.4 Technical parameters) Power supply need to be grounded (Judging method: test the live wire and the neutral wire of the main socket with multimeter. The voltage between live and ground should equal to the voltage of local electrical grid, and the voltage between neutral wire and ground should be zero, otherwise the power grounding is bad) 1.5 Installation... -
Page 9: Inspection After Installation
Take out the M10 × 55 hexagon socket head bolt, flat washer 10, spring washer 10, and cover nut M10 from the attachment, assemble the base according to the diagram, and tighten it firmly. 1.6 Inspection after Installation Refer to this table and follow the instruction in 2.3.2, check the following items after powering on the Fume Hood. -
Page 10: 2Operating Principle/Air Flow Pattern
bases should NOT be conducted by this FH-12L-Integral Fume Hood. 2.1.2Operating principle/air flow pattern Picture 10 2.1.3Protected object The primary goal of the Fume Hood is to protect operators and laboratory environment from exposure to infectious aerosol and toxic gas which may be generated from the reaction during experiments. - Page 11 Noise ≤68dB（A） Model FH-13L FH-15L FH-18L Parameter Rated Voltage AC 220V±10% □ 110V±10% □ Rated Frequency 50 Hz □ 60Hz □ External Dimension 1300*800*1260mm 1500*800*1260mm 1800*800*1260mm （desktop）(W*D*H)) External Dimension （Overall type） 1300*800*2000mm 1500*800*2000mm 1800*800*2000mm (W*D*H)) Working Zone 1180*720*835mm 1380*720*835mm 1680*720*835mm Dimension (W*D*H) Power Supply 500 W...
-
Page 12: Product Structure 2.2
Product Structure 2.2 2.2.11Structural composition of FH-L-Series Fume Hood Picture 11 1、 Work table 2、POWER 3、Fluorescent Lamp 4、Glass door control switch 5、Fan speed control knob 6、front panel 7、Tempered glass window 8、Glass lifting motor 9、Socket fuse 10、charging connector 11、Built in fan 2.2.2 Structure introduction ★... -
Page 13: Instructions Of Operation
Fluorescent Lamp: The lighting switch is the control switch for lighting fixtures. Glass door up and down switch: Continuously press the upward direction of the glass door, and the glass door will continue to rise until it reaches the highest point of travel. When the button is released, the glass door will immediately stop moving. -
Page 14: Regular Maintenance
d、 Rotate the fan knob clockwise to start the fan. Continue to rotate the fan knob clockwise to adjust the appropriate wind speed. After running for 5 minutes, the experimental operation inside the cabinet can be carried out normally; e、Press the lighting switch to turn on the lights. Press the lighting switch again to turn off the lights (you can choose to turn on or off the lights according to the laboratory environment);... -
Page 15: Replacement Parts List
than one year needs to be unpacked and checked before selling and using. Only the tested and qualified safety cabinet could be sold. 2.5 Replacement Parts List FH-7L Fume Hood Replacement Part List Part Name Specification Fuse tube Fluorescent lamp T5 4W Blower 250 pp axial flow fan... - Page 16 Ship type switch KCD4 Glass door control switch Three level self recovery KCD2 Wind speed adjustment knob tubular motor SF45-20S Front window glass 1000*645*5 FH-12L Fume Hood Replacement Part List Part Name Specification Fuse tube Fluorescent lamp T5 12W Blower 250 pp axial flow fan Ship type switch KCD4...
- Page 17 FH-15L Fume Hood Replacement Part List Part Name Specification Fuse tube Fluorescent lamp T5 14W Blower 250 pp axial flow fan Ship type switch KCD4 Glass door control switch Three level self recovery KCD2 Wind speed adjustment knob tubular motor SF45-20S Front window glass 1400*645*5...
-
Page 18: Wiring Diagram
2.6 Wiring Diagram Picture 13 3.Common Failures and Solutions 3.1 Trouble shooting Please confirm that the power is well connected, whether the power cord is obvious damaged, the circuit and the fuses are in good condition. 1. In order to ensure the maintenance and use of security,you need check whether the equipment has a reliable grounding measures according to the manual.To check whether the electrical wiring of the equipment is off, broken and short circuit .It should be excluded if similar situation appears. - Page 19 Circuit Check the circuit Control panel Replace the control panel Socket fuse Check if the socket fuse is broken No electricity in Socket Check if the socket is broken socket Circuit Check the circuit Check whether the power supply is well Power supply connected Power cord...
-
Page 20: Label Description
Remove used fluorescent light .Install a new lamp tube by pushing it in and connecting with the power cord. Picture 15 NOTE: a) The above trouble shooting methods should be done by qualified electricians under safe conditions (cut off power supply). Other components should not be removed. Risk caused by failing to follow those instructions would be responsible by user. -
Page 21: Warranty
4.Warranty 4.1. Warranty is 12 months from EX-factory date (excluding consumable accessories, UV and Fluorescent lamp, fuse) 4.2. Our company would not be responsible for any repair of damage caused by improper operation 4.3. If the warranty has been expired, us would still responsible for repair with relative charges 4.4.
