E3901i / E3902i
Induction Boiling Tables
INSTALLATION and
SERVICING INSTRUCTIONS
IMPORTANT
The installer must ensure that the installation of the appliance is in conformity with these instructions
and National Regulations in force at the time of installation. Particular attention MUST be paid to –
BS7671 IEE Wiring Regulations
Health and Safety At Work Act
WARNING
READ THESE INSTRUCTIONS BEFORE INSTALLING THIS APPLIANCE.
BEFORE ATTEMPTING ANY MAINTENANCE, ISOLATE THE APPLIANCE AT THE MAINS
ISOLATING SWITCH AND TAKE STEPS TO ENSURE THAT IT CANNOT BE INADVERTENTLY
SWITCHED ON.
IT IS MOST IMPORTANT THAT THESE INSTRUCTIONS BE CONSULTED BEFORE INSTALLING
AND COMMISSIONING THIS APPLIANCE. FAILURE TO COMPLY WITH THE SPECIFIED
PROCEDURES MAY RESULT IN DAMAGE AND NEED FOR A SERVICE CALL.
On completion of the installation these instructions should be left with the Engineer-in-Charge for
reference during servicing. In addition, the Users Instructions should be handed to the User, having
had a demonstration of the operation and cleaning of the appliance.
PREVENTATIVE MAINTENANCE CONTRACT
To obtain maximum performance from this unit regular servicing of the appliance should be undertaken to ensure
correct operation, it is functioning as intended, and safe to use. We recommend servicing in accordance with
SFG20 Maintenance Schedules and as a minimum, after 2,500 hours of use, or annually, whichever comes
that a maintenance contract be arranged with an appointed service contact. Visits may then be made at agreed
intervals to carry out adjustments and repairs.
WEEE Directive Registration No. WEE/DC0059TT/PRO
At end of unit life, dispose of appliance and any replacement
parts in a safe manner, via a licenced waste handler.
Units are designed to be dismantled easily and recycling of all
material is encouraged whenever practicable.
Falcon Foodservice Equipment
Wallace View, Hillfoots Road, Stirling, FK9 5PY, Scotland
Service Contact
Phone: 01438 363 000
Email:
servicesupport@service-line.co.uk
Electricity at Work Regulations
Fire Precautions Act
first and
T100803 Ref. 10
Advertisement
Table of Contents
Related Manuals for Falcon Dominator Plus E3902i
Summary of Contents for Falcon Dominator Plus E3902i
- Page 1 Units are designed to be dismantled easily and recycling of all material is encouraged whenever practicable. Falcon Foodservice Equipment Wallace View, Hillfoots Road, Stirling, FK9 5PY, Scotland Service Contact Phone: 01438 363 000 Email: servicesupport@service-line.co.uk...
- Page 2 IMPORTANT INFORMATION ELECTRICAL SAFETY AND ADVICE REGARDING SUPPLEMENTARY ELECTRICAL PROTECTION Commercial kitchens and foodservice areas are environments where electrical appliances may be located close to liquids, or operate in and around damp conditions or where restricted movement for installation and service is evident.
- Page 3 Warranty Policy Shortlist Warranty does not cover :- • Correcting faults caused by incorrect installation of a product. • Where an engineer cannot gain access to a site or a product. • Repeat commission visits. • Replacement of any parts where damage has been caused by misuse. •...
-
Page 4: Section 1 - Installation
SECTION 1 - INSTALLATION UNLESS OTHERWISE STATED, PARTS WHICH HAVE BEEN PROTECTED BY THE MANUFACTURER ARE NOT TO BE ADJUSTED BY THE INSTALLER. 1.1 MODEL NUMBER, NETT WEIGHT and DIMENSIONS Width Depth Height Weight Model (mm) (mm) (mm) (kg) E3901i Induction Table on legs E3901i Induction Table on castors... -
Page 5: Section 2 - Assembly And Commissioning
After installation, the engineer should check satisfactory operation and demonstrate method of use to kitchen staff. Location of mains isolating switch should be identified for use in the event of an emergency or during cleaning. SECTION 2 - ASSEMBLY and COMMISSIONING NOTE: Users MUST be made aware that individuals fitted with a pacemaker should consult their doctor if in close proximity to this unit. -
Page 6: Section 3 - Servicing, Maintenance And Conversion
SECTION 3 - SERVICING, MAINTENANCE AND CONVERSION BEFORE ATTEMPTING ANY MAINTENANCE, ISOLATE THE APPLIANCE AT THE MAINS ISOLATING SWITCH AND TAKE STEPS TO ENSURE THAT IT CANNOT BE INADVERTENTLY SWITCHED ON. MAINTENANCE CHECK Regular servicing of the appliance should be undertaken to ensure correct operation, it is functioning as intended, and safe to use. - Page 7 3.4 CERAMIC HOB ASSEMBLY Remove control panel as detailed in Section 3.1. Remove 2 fixings that secure hob at front. Remove 2 fixings that secure hob to rear panel. Carefully lift and remove top frame/glass-ceramic plate assembly, and lay on a flat surface. If replacing hob in the event of glass damage, ensure any glass debris is cleared away from induction coils and from inside of unit.
-
Page 8: Section 4 - Spares
SECTION 4 - SPARES When ordering spare parts, always quote appliance type and serial number. This information will be found on data badge attached to base plate. 3.5kW Generator Assembly 5kW Generator Assembly 3.5kW Induction Coil 5kW Induction Coil Control Knob Control Switch &... - Page 9 5.2.1 10kW model Terminal I Actual I Max I Min 15.3A 16.8A 14.5A 15.3A 16.8A 14.5A 15.3A 16.8A 14.5A Total 45.9A 50.4A 43.5A 5.2.2 7kW model Terminal I Actual I Max I Min 10.7A 10.3A 10.7A 10.3A 10.7A 10.3A Total 32.1A 30.9A Note:...
- Page 10 SECTION 6 - TROUBLESHOOTING SUPPLY PROTECTION DEVICE The appliance is fitted with a miniature circuit breaker (MCB) as additional protection against over current. If unit fails to operate or show any operational indicators, Follow details in Error Code Table before calling a service engineer.
- Page 11 Error Name Cause Corrective action E1-04 Cooking zone temperature too Pan empty Remove pan, switch off Appliance and wait a high. couple of minutes for the appliance to cool E1-06 Internal Temperature too high Air routes blocked. Switch off appliance, clean air units E1-07 Coil Temperature.
- Page 12 WIRING DIAGRAM...
