USERS, INSTALLATION AND SERVICING INSTRUCTIONS
ELECTRIC BRATT PAN
E3800
DATE PURCHASED:
MODEL NUMBER:
SERIAL NUMBER:
DEALER:
T100839 Rev.8
SERVICE PROVIDER:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dominator Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Falcon Dominator Plus

Summary of Contents for Falcon Dominator Plus

  • Page 1 USERS, INSTALLATION AND SERVICING INSTRUCTIONS ELECTRIC BRATT PAN E3800 DATE PURCHASED: MODEL NUMBER: SERIAL NUMBER: DEALER: T100839 Rev.8 SERVICE PROVIDER:...
  • Page 2 Dear Customer, Thank you for choosing Falcon Foodservice Equipment. This manual can be downloaded from www.falconfoodservice.com where you also can see the full range of our products and latest news. IMPORTANT: Please keep this manual for future reference. SYMBOLS PLEASE READ THIS MANUAL This manual should be read carefully before operating, installing or servicing the appliance.

  • Page 3: Table Of Contents

    Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland. SERVICELINE CONTACT Phone: 01438 363 000 CONTENTS INTRODUCTION ..........................4 OPERATION ............................6 Controls .............................. 7 Using the Bratt Pan .......................... 7 GETTING THE MOST OUT OF THE APPLIANCE ................ 8 CLEANING AND MAINTENANCE ....................9 SPECIFICATION ..........................

  • Page 4: Introduction

    INTRODUCTION This appliance has been CE-marked on the basis of compliance with the Low Voltage and EMC Directives for the voltages stated on the data plate as shown below: IMPORTANT!       ...
  • Page 5        It is most important that these instructions be consulted before operating, installing and commissioning this appliance. Failure to comply with the specified procedures may result in damage or the need for a service call. ...

  • Page 6: Operation

    OPERATION...

  • Page 7: Controls

    Controls Turn handle • OFF Position to lift pan up and down. Variable temperature setting 100°C - 300°C. Indicates that Indicates when Turn tap to turn the heating mains electricity water ON and element is ON. is ON. OFF. Using the Bratt Pan Ensure pan is fully lowered using the pan tilting handle.

  • Page 8: Getting The Most Out Of The Appliance

    Turn mains electricity ON. The Red neon will illuminate. Turn thermostat control knob to desired temperature. Amber neon will illuminate. When the desired temperature is reached, the Amber neon will go OFF. If cooking a liquid based food, ensure it does not go over the MAX mark as shown below.

  • Page 9: Cleaning And Maintenance

    Griddling Note that the centre of the pan is hotter than the edges when griddling. Simmering and Stewing Lid can be left slightly ajar if a gentle simmer is desired. As mentioned in griddling, the centre of the pan is hotter so the content may tend to stick to the pan more around the middle. CLEANING AND MAINTENANCE All surfaces are easier to clean if spillage is removed before it becomes burnt on and if appliance is cleaned daily.

  • Page 10: Model Number Covered In This Group Of Products

    Model Number covered in this group of products E3800 800mm wide manual lift electric Bratt Pan Technical Data TECHNICAL DATA - TABLE A MODEL NUMBER E3800 Total Power (kW) 11.2 Current (A) at 11.2 230V 11.2 DIMENSIONS / ELECTRICAL CONNECTION LOCATIONS INSTALLATION...

  • Page 11: Unpacking

    Unpacking 1. Remove all packaging from the appliance. 2. Remove all plastic coating that is on the appliance by peeling them off. 3. Ensure there are no missing parts to the appliance. 4. Ensure there are no damages to the appliance. 5.

  • Page 12: Electric Supply & Connection

    Electric Supply & Connection The location of the electrical connection is shown in “Dimensions/Electrical Connection Location” Chapter. The appliance is suitable for AC supplies only. The standard terminal arrangement is: 3 phase & neutral 5 wire connection (400V 3N~) Phase 1 Phase 2 Phase 3 Neutral...

  • Page 13: Commissioning

    Commissioning NOTE: Prior to operation, ensure that ALL packing material has been removed. For instructions on how to use the appliance, see ‘Operation’ chapter. For relevant figures, please see ‘Technical Data’. 1. Turn appliance on and ensure Red Neon illuminates. 2.
  • Page 14 REMOVAL OF FRONT FASCIA / ACCESS TO ELECTRICS BOX To gain access to the electrics box, first the front fascia must be removed.
  • Page 15 When removing the front fascia, care should be taken not to damage the neon cables. NEONS Neons are attached to the front fascia. To replace them, remove the connections and the nut.
  • Page 16 OPERTAING THERMOSTAT The operating thermostat is located on the cover of the electrics box. To replace, remove the clip that secures the thermostat capillary. Pull out thermostat phial then remove the two screws on the cover of the electrics box.. When replacing the thermostat phial back into the hole, ensure that the phial is pushed right back into the tube and reattach the Vidaflex.
  • Page 17 SAFETY THERMOSTAT Safety thermostat is located on the left side of the electrics box. Push the button protruding out from the bottom of the box to reset. To replace, remove the same clip that’s shown in the operating thermostat. Pull out phial then remove the two screws. When replacing the thermostat phial back into the hole, ensure that the phial is pushed right back into the tube and reattach the Vidaflex.
  • Page 18 CONTACTOR The contactors are located in the electrics box. To replace, lever it out by using a flat headed screwdriver. ELEMENTS Lift Pan fully up to get access to the Element Box. To gain access to just the element connections, remove the element connection cover a shown below.
  • Page 19 To replace the elements, first the element box must be removed as shown. When replacing the bottom two elements, the thermostat tube must be removed as well. They are all attached by hex nuts. When replacing the Elements, ensure it is secured tightly to the pan base.

  • Page 20: Wiring Diagram(S)

    Ensure Thermostat Tube is attached tightly to the Elements. Wiring Diagram – 400V 3N~ Appliance...
  • Page 22 Wiring Diagram – 440V 3N~ Appliance...

  • Page 23: Fault Finding

    FAULT FINDING FAULT POSSIBLE CAUSES REMEDY Red and Amber neon not No power from the supply. Restore supply. lighting. Blown fuse. Replace fuse. Faulty mains supply cord. Replace supply cord. Faulty Neons. Replace Neons. Amber neon not lighting but Safety Thermostat tripped or Reset Thermostat.

  • Page 24: Service Information

    SERVICE INFORMATION In order to obtain maximum performance from this appliance we would recommend that a maintenance contract be arranged with SERVICELINE. Visits may then be made at agreed intervals to carry out adjustments and repairs. A quotation will be given upon request to the contact number below: SERVICELINE CONTACT: Phone: 01438 363 000...
  • Page 25 • Re-setting or adjustment of thermostats when appliance is operating to specification. • Cleaning and unblocking of fryer filter systems due to customer misuse. • Lubrication and adjustment of door catches. • Cleaning and Maintenance • Cleaning of burner jets •...
