Gazebo penguin 43224-22 Assembly Instructions Manual

12'x14'
Hide thumbs

Advertisement

Quick Links

Download this manual
43224-22
BROWN
43224-32
SLATE
12'x14' GAZEBO
ASSEMBLY INSTRUCTIONS
DO NOT DESTROY THE BOXES UNTIL COMPLETELY ASSEMBLED
PLEASE VERIFY THE CONTENT OF EACH BOX AGAINST THE LIST OF PARTS
Assembly With Two Or More Adults Recommended
Base Dimensions 10' 11" x 13' 4"
APPROX.
Largest Dimensions 11' 11" x 14'
Overall Height 108.5''
ZZZ-204.43224.0210-21.GP.EN.doc
WEB VERSION
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 43224-22 and is the answer not in the manual?

Questions and answers

Related Manuals for Gazebo penguin 43224-22

Summary of Contents for Gazebo penguin 43224-22

  • Page 1 43224-22 BROWN 43224-32 SLATE 12’x14’ GAZEBO ASSEMBLY INSTRUCTIONS DO NOT DESTROY THE BOXES UNTIL COMPLETELY ASSEMBLED PLEASE VERIFY THE CONTENT OF EACH BOX AGAINST THE LIST OF PARTS Assembly With Two Or More Adults Recommended Base Dimensions 10’ 11” x 13’ 4”...
  • Page 2 Some jurisdictions may require permits for, or otherwise regulate, installation and use. For assistance with assembly, installation, parts, or customer service, contact Gazebo Penguin Customer Service Department at the numbers listed below (English & French, Mon-Fri 8:00 AM to 4:00 PM EST):...
  • Page 3 3. Leaking due to heavy rain may happen, please refer to the instruction manual for window positions and information on how to evacuate the water. 4. The product is only warranted in the event it is installed in accordance with the Gazebo Penguin’s written instructions enclosed with the product.
  • Page 4 Before You Assemble the Gazebo PLEASE DON'T DESTROY BOXES UNTIL COMPLETELY ASSEMBLED  Please verify the content of each box against the list of parts.  It is important that this gazebo be anchored on a solid base with the provided screws. Otherwise, please ensure that you use anchors sufficient for your surface.
  • Page 5 ZZZ-204.43224.0210-21.GP.EN.doc WEB VERSION...
  • Page 6 Step 2: For each leg “G”, attach foot plate “H” using 3 bolts “Pp”. Step 3: 1. Unscrew 4 Pp Bolts as shown below, have someone lift the Beam assembly and attach each Leg “G” into a Corner, again securing each using 4 Bolts “Pp”. 2.
  • Page 7 Step 4: 1. Install Middle Cover “J” at each of the 4 beam junctions, using 4 Screws “Qq” each. Install Corner Cover “I” at each of the corners, using 4 Screws “Qq” each. ZZZ-204.43224.0210-21.GP.EN.doc WEB VERSION...
  • Page 8 Step 5: 1. Attach Mounting Brackets “O” to Rafters “M”, and Mounting Brackets “P” to Rafters “N” and “N-2”. Use threaded hole about 8½” & 5” from end of rafter. 2. Lift Central Hub “L” to a height of about 110” (2.79m) at the center of the gazebo. (Caution: this part may be heavy, use support as needed) 3.
  • Page 9 Step 7: Install the flashings “Q”, “R”, “S”, and “S-2” onto the beam assembly, using screws “Qq” on the inside. The notched end of a flashing will always go in a corner of the gazebo. Step 8: Install the curtain rails “T” and “U” on the inside of the beam assembly using bolts “Pp”. ZZZ-204.43224.0210-21.GP.EN.doc WEB VERSION...
  • Page 10 Step 9: Slide the indicated polycarbonate panels into the spaces between the rafters, using the top groove of each rafter. Ensure the side meant to face the sun is on the outside. Use a rubber hammer to carefully tap each panel into the grooves. Step 10: Insert the middle roof joints in between the rafters and slide them up under the polycarbonate panels.
  • Page 11 Step 11: 1. Slide the remaining polycarbonate roof panels in the lower groove of the rafters and into the lower slot of the roof joints. Tap to make sure panels fit securely and do not extend past the ends of the rafters. Step 12: 1.
  • Page 12 Step 13: 1. Install the upper crossbars on the interior of the roof using bolts “Pp”, following the shaped ends and letters. Do not tighten bolts immediately; install loose and tighten once all crossbars are in place. 2. Repeat this step with the lower crossbars.
  • Page 13 Step 15: 1. Install the Screen Curtains “Ww” in the interior groove of the Curtain Rails, using the provided hooks. Install the Privacy Curtains “Xx” in the exterior groove of the rails. Once the hooks are in, use Curtain Rail Caps “Uu” to close ends of curtain rails. Note that both curtains are packaged and Ww/Xx ordered in sets of 2 panels, each set covering...
  • Page 14 43224 BROWN (see page 18 for Slate parts) PART DIAGRAM PART DIAGRAM (11-626-22) (11-665-22) 65 ½” 60” TOP LEFT BEAM CENTRAL HUB (11-627-22) (11-731-22) 65 ½” 92 5/8” TOP RIGHT BEAM ROOF RAFTER (11-662-22) (11-708-22) 78 ¼” 73 ¾” TOP LEFT BEAM ROOF RAFTER (11-663-22) (11-637-22)
  • Page 15 PART DIAGRAM PART DIAGRAM (11-666-22) (11-664-22) 73 ¼” 63” CURTAIN TOP CAP RAIL, 14’ SIDE (11-678-22) (11-641-22) 32 ¼”x72” 60 ½” LEFT LOWER CURTAIN RAIL, PANEL, 12’ 12’ SIDE SIDE (11-721-22) (11-674-22) 39”x57 ½” 31”x38” LEFT LOWER LEFT UPPER PANEL, 14’ PANEL, 12’...
  • Page 16 PART DIAGRAM PART DIAGRAM (11-713-22) (11-653-22) 38 ½” 58 7/8” RIGHT MID RIGHT ROOF JOINT EDGING, 12’ SIDE 14’ SIDE (11-647-22) (11-651-22) 25 ½” 58 7/8” CENTER LEFT MIDDLE EDGING, 14’ SIDE ROOF JOINT Ff-2 (11-677-22) 31” (11-654-22) RIGHT MID RAFTER ROOF JOINT, 14’...
  • Page 17 PART DIAGRAM PART DIAGRAM (08-193-22) (11-683-22) PLASTIC 53 ½” PLUG RIGHT LOWER CROSSBAR, (08-187-22) 12’ SIDE WASHER (M6) (11-697-22) CURTAIN (11-718-22) RAIL CAP 53 ½” LEFT LOWER CROSSBAR, (08-189-22) 12’ SIDE ACORN Kk-2 (11-685-22) 20 ½” (11-686) RIGHT UPPER SCREEN/ CROSSBAR, MOUSTIQUAIRE 12’...
  • Page 18 43224 SLATE PART DIAGRAM PART DIAGRAM (11-626-32) (11-665-32) 65 ½” 60” TOP LEFT BEAM CENTRAL HUB (11-627-32) (11-731-32) 65 ½” 92 5/8” TOP RIGHT BEAM ROOF RAFTER (11-662-32) (11-708-32) 78 ¼” 73 ¾” TOP LEFT BEAM ROOF RAFTER (11-663-32) (11-637-32) 78 ¼”...
  • Page 19 PART DIAGRAM PART DIAGRAM (11-666-32) (11-664-32) 73 ¼” 63” CURTAIN TOP CAP RAIL, 14’ SIDE (11-678-32) (11-641-32) 32 ¼”x72” 60 ½” LEFT LOWER CURTAIN RAIL, PANEL, 12’ 12’ SIDE SIDE (11-721-32) (11-674-32) 39”x57 ½” 31”x38” LEFT LOWER LEFT UPPER PANEL, 14’ PANEL, 12’...
  • Page 20 PART DIAGRAM PART DIAGRAM (11-713-32) (11-653-32) 38 ½” 58 7/8” RIGHT MID RIGHT ROOF JOINT EDGING, 12’ SIDE 14’ SIDE (11-647-32) (11-651-32) 25 ½” 58 7/8” CENTER LEFT MIDDLE EDGING, 14’ SIDE ROOF JOINT Ff-2 (11-677-32) 31” (11-654-32) RIGHT MID RAFTER ROOF JOINT, 14’...
  • Page 21 PART DIAGRAM PART DIAGRAM (08-193-32) (11-683-32) PLASTIC 53 ½” PLUG RIGHT LOWER CROSSBAR, (08-187-32) 12’ SIDE WASHER (M6) (11-697-32) CURTAIN (11-718-32) RAIL CAP 53 ½” LEFT LOWER CROSSBAR, (08-189-32) 12’ SIDE ACORN Kk-2 (11-685-32) (11-686) 20 ½” SCREEN/M Left RIGHT UPPER OUSTIQUA CROSSBAR, 12’...
  • Page 22 NOTE: The Dimensions Are Approximate. ZZZ-204.43224.0210-21.GP.EN.doc WEB VERSION...
