Ballard Designs Lucia Extension Dining Table Manual

Download this manual

PRODUCT NAME: Lucia Extension Dining Table

ITEM NUMBER: SL169

ASSEMBLED DIMENSIONS : 30"H x 108"W x 40"D

PRODUCTS ARE NOT INTENDED

FOR COMMERCIAL USE.

UPDATED: 12-14-2020

Prevent accidentally discarding small parts or

hardware. Retain all carton contents until assembly

and installation are complete.

Customer Service: 800-367-2810

Online: www.ballarddesigns.com

MADE IN CHINA

Page 1 of 4

Need help?

Do you have a question about the Lucia Extension Dining Table and is the answer not in the manual?

Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Lucia Extension Dining Table ITEM NUMBER: SL169 ASSEMBLED DIMENSIONS : 30”H x 108”W x 40”D Prevent accidentally discarding small parts or hardware. Retain all carton contents until assembly and installation are complete. PRODUCTS ARE NOT INTENDED MADE IN CHINA FOR COMMERCIAL USE.
Page 2 Assemble in location for intended use. Leaf (F) Legs (G) (Boxed) Top (E) (Boxed) Hardware REQUIRED TOOLS: Packet Allen Wrench (included) -Two person assembly suggested. Remove all parts, hardware and protective packaging from carton and carefully arrange on a clean, level, padded surface.
Page 3 Assemble in location for intended use. STEP 1: Invert Top (E) onto a clean, padded, level surface then attach a Leg (G) to each corner as illustrated. Secure Legs using Allen Bolt (C) with Lock Washer (B) and Flat Washer (A). Insert and hand tighten all Bolts before using Allen Wrench (D) to fully tighten.
Page 4 INSTALLING EXTENSION LEAF 1. Open both Table Locks located under table edge and pull Top apart. 2. Turn Apron down on each end of Leaf. 3. Place Leaf into opening and align wood and metal pins with holes in edge of Top surface. 4.

Sl169
