- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Lauren Wall Desk ITEM NUMBER: WS987 ASSEMBLED DIMENSIONS : 17 1/2”H x 30”W x 9 1/8”D PRODUCTS ARE NOT INTENDED MADE IN CHINA FOR COMMERCIAL USE. UPDATED: 3-31-2020 Page 1 of 6...
-
Page 2: Required Tools
Assemble in location for intended use. WARNING Falling Hazard Wall Decor is HEAVY and requires adequate support. Wall Brackets must be firmly attached to WALL STUDS. REQUIRED TOOLS: Phillips Screwdriver, Level, Pencil, Drill. 1/4” and 3/8” bit -Two person assembly suggested. Remove all parts, hardware and protective packaging from carton and carefully arrange on a clean,... - Page 3 STEP 1: Determine installation site and locate at least two WALL STUDS in wall behind Desk. Use a level to position Wall Bracket (F) and center a hole over each WALL STUD. Insert and drive Screw (A) directly into WALL STUD. For holes located in open drywall (no stud) use an Expansion Bolt (B). See Step 2 for installation instructions.
- Page 4 STEP 3: Use a screwdriver to press down and firmly turn screw clockwise until it begins to slip indicating the barrel has crimped against inside of drywall. Back out and completely remove Screw, leaving bolt/anchor in wall. Position Bracket (F), align holes, replace and tighten Screw. Barrel Turn screw until it slips Remove screw...
- Page 5 STEP 5: Carefully open and fold down door and use a pencil to mark location for both screw holes on the inside bottom edge of Desk (E). STEP 6: Carefully lift and remove Desk (E) from wall. Use a drill with a 1/4” bit to create a pilot hole at each mark then gently tap Wall Anchors (C) into place until flush with wall surface.
- Page 6 STEP 7: Return Desk (E) to wall and lock onto Bracket. Align both interior holes with Wall Anchors, insert Screw (A), fully tighten, then cover hole with Wood Plug (D). Cleaning & Care: DO NOT use alcohol based products or spray polisher as they can damage the finish. Dust with soft cloth.
