PRODUCT NAME: MS134
ITEM NUMBER: CF Josephina Media Console
ASSEMBLED DIMENSIONS: 31"H x 62"W x 13"D
PRODUCT NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 1-19-2022
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN ITALY
Page 1 of 5
Advertisement
Table of Contents
Related Manuals for Ballard Designs CASA Florentina Josephina MS134
Summary of Contents for Ballard Designs CASA Florentina Josephina MS134
- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: MS134 ITEM NUMBER: CF Josephina Media Console ASSEMBLED DIMENSIONS: 31”H x 62”W x 13”D Prevent accidentally discarding small parts or hardware. Retain all carton contents until assembly and installation are complete. PRODUCT NOT INTENDED MADE IN ITALY FOR COMMERCIAL USE.
- Page 2 Assemble in location for intended use. Ltr. Qty. Hardware Included REQUIRED TOOLS: Phillips Screwdriver Shelf Supports Leveler Tool (included) - Two person assembly suggested. Connector Brackets Remove all parts, hardware and (For joining 2 or more units protective packaging and carefully arrange on a clean, level surface.
- Page 3 Assemble in location for intended use. STEP 1: Console (I) is equipped with removable Base Moulding (G). On a soft, padded surface gently lay Console backside down. Orient base molding with square edge to back and insert Bolts (D) through pre-drilled holes and into T-nut in Base Molding.
- Page 4 Assemble in location for intended use. STEP 3: Determine placement for Shelves (H) then insert Shelf Supports (A) into corresponding pre-drilled holes inside Console (I). Tilt in and gently lay Shelf upon Supports. STEP 4: (OPTIONAL) Muliple Casa Florentina Josephina components (each sold separately) may be joined together into a single unit.
- Page 5 WALL ANCHORING HARDWARE (ANTI-TIP) Ltr. Qty. Hardware Included Large Screw Small Screw WARNING Tip-Over Hazard Bracket Serious or fatal crushing injuries can occur from a furniture tip-over Prevent tipping accidents. Anchor your furniture. Retention Belt Installation: 1. Place furniture against wall at desired location then locate and mark a Wall Stud behind unit. 2.
