Safe-Cell
Prison Tapware
PRODUCT CODE:
- 50121C
- 50124C
SPECIFICATIONS
−
Designed for maximum protection against vandalism, Safe-Cell
heavy duty components and can be installed from the rear.
−
The basin/sink assembly is made of chrome plated brass.
−
Quarter turn ceramic disc.
−
Machined cold or hot identification button.
−
Anti-ligature design.
−
Available with either Ezy-Grip or Multi-Grip handle (as shown above).
IMPORTANT: All Safe-Cell
working order.
TECHNICAL DATA
Inlet
Outlet
Headwork
Working Pressure Range (kPa)
Maximum Working Temperature (°C)
Nominal Flow Rate (LPM)
Finish
NOTE: Galvin Specialised continually strive to improve their products. Specifications may change without notice.
PRE-INSTALLATION
MOUNTING DETAILS
−
If the mounting holes do not already exist, mark out
and drill the holes in the bench/trough, as shown in
rough-in dimensions.
Note: Supplied flexi hose length is 225mm long.
Maximum distance between outlet and body
adjustment is 140mm.
TOOLS REQUIRED
−
Power drill
−
Spanner or adjustable crescent
−
Thread tape / sealant
®
prison taps are tested in accordance with AS/NZS 3718 and leave our premises in good
Version 1, 22 November 2016, 1 of 4
®
basin/sink assemblies are made from
15BSP Male & 15CU
N/A
Ceramic
Min
50
Max
500
Min
5
Max
85
6
Chrome
2
2
3
3
7
5
m
m
M
n i
1
4
0
m
m
M
x a
FLOW DIRECTION
BENCH / TROUGH
4
