Summary of Contents for XAG RevoMower 2
- Page 2 To User Dear user, thank you for choosing XAG's products. For safety purposes and better user experience, it is highly recommended that you read this manual carefully and strictly follow the instructions hereof. Contact Us Manufacturer: Guangzhou Xaircraft Technology CO., LTD.
-
Page 3: Table Of Contents
Contents Disclaimer Safety Guidelines List of Items Main Components Installation Install RevoMower Connect Cooling Tube Wire Cables Add Coolant Use of Device Power On Use of ARC3 Maintenance Cleaning After Operation Regular Maintenance Appendix Wiring Quick Guide Specifications... -
Page 4: Disclaimer
However, this does not imply that the terms contained in this Disclaimer are necessarily invalid. 11. To the extent permitted by law, XAG reserves the rights for final explanation and revision of the terms and conditions hereinabove. XAG also has the right to update, modify or terminate these terms and conditions via channels including its official website, the User Manual and online App, without prior notice. -
Page 5: Safety Guidelines
User is required to read through the User Manual and obtain an operator certificate, if any, accredited by XAG or existing laws, regulations and policies. Otherwise, it may cause serious injury to yourself or others, or damage to the product and property loss. User should be strongly safety-conscious. This product is not suitable for those who are under 18 years old, or those who have no or limited capacity for civil conduct, or those with mobility impairments. -
Page 7: Installation
Heading Direction Radiator Tank Shield Lifter Motor Left Rubber Sheet Blade Handle Blade Motor Blade Front Rubber Sheet Right Rubber Sheet Installation Install RevoMower Remove Motor Shield Unscrew eight M10*16 hex screws that fix the motor shield, and remove the shield. Motor Shield M10*16 Hex Screw www.xa.com/en... - Page 8 Place Cutting Disc Assembly Install the cutting disc assembly on the bottom of the vehicle with the front rubber sheet in heading direction. Heading Direction Cutting Disc Assembly Fix Servo Assembly ① Fix right servo assembly on the right of vehicle using two M10*20 hex bolts. ②...
-
Page 9: Connect Cooling Tube
Connect Cooling Tube ① Connect the water supply tubes of left and right motors, and tighten the tubes using tube clips. ② Connect the water discharge tubes of left and right motors, and tighten the tubes using tube clips. Water Supply Tube of Right Motor ①... -
Page 10: Add Coolant
① Connect D (318 Limit Switch-R), F (317 Servo-R), C (320 Payload System-CAN-R) and B (319 Payload System-CAN-L) in turn, referring to "Wiring Quick Guide – XAG RevoMower 2". ② Connect A (305 CAN Signal), 301 Left Power Supply +, 302 Left Power Supply -, 303 Right Power Supply + and 304 Right Power Supply - in turn. -
Page 11: Use Of Device
Use of Device Power On Install the battery in the vehicle and power it on, then the mower automatically rises until the limit sensors on the left and right sides sense the induction patches, and the mower returns to the starting position and stops rising. -
Page 12: Maintenance
Maintenance After operation, check the vehicle's components and clean its surface so as not to cause damage. Cleaning After Operation Clean the vehicle and the inside of the blade cover after each operation to prevent them from corrosion by foreign objects including grass, leaves and mud, which will result in a shortened lifespan. The cleaning steps are as follows: Detergent: clean water, soapy water or laundry powder/water mixture... - Page 13 4. Secure the blade with a high-strength rod; 5. Unscrew both nuts from the blade, remove the cap, bushing, bolt and blade. 6. Put the new blade and handle back in place, and make sure that the bolt and nuts are tightened. Bushing Bushing Blade...
-
Page 14: Appendix
Appendix Wiring Quick Guide The diagram below will guide you through the process of wiring the module. www.xa.com/en... -
Page 15: Specifications
Specifications Model M4RM-900A Installation Mounted Cutter Type Rotary Cutting Width 900 mm Cutting Height 20-170 mm Speed Control of Blades Manually Cooling Method Liquid cooling Blade Quantity Drive Mode of Blades Direct drive Rated Speed 1800 RPM Max. Speed 3300 RPM Power of Single Motor 3000 W Rated Torque...
