Key Automation KIT RAY2524EK Instructions And Warnings For Installation And Use page 18

EN
TABLE OF CONTENTS
1 Safety warnings
2 Product Introduction
2.1 Description of the control unit
2.2 Description of the connections
2.3 Models and technical characteristics
2.4 List of cables required
3 Preliminary Checks
4 Installing the Product
4.1 Electric connections
4.2 Using the display programmer
4.3 Auto-learning of the travel stroke
Operating the automation using the display program-
4.4
mer
4.5 Operating the automation using the receiver
4.6 Diagnostic
4.7 Customising the system - Basic settings 14A
4.8 Night lights
5 Testing and commissioning
5.1 Testing
5.2 Commissioning
6 Details
6.1 Customising the system - Advanced settings 14A
6.2 RX4X RECEIVER
6.3 Programmer flow chart
7 EC declaration of conformity
18
p. 19
p. 21
p. 21
p. 21
p. 21
p. 22
p. 22
p. 23
p. 23
p. 25
p. 25
p. 26
p. 26
p. 27
p. 27
p. 29
p. 29
p. 29
p. 29
p. 30
p. 30
p. 32
p. 33
p. 130
