Installation guide:
1. Place the machine in a flat place where
the airoutlet is not blocked and the distance
from the wall should exceed 11.81inch(30cm),
as shown on the right.
2. The socket must meet the electrical safety
requirements of EU .
Tips:
The installation of exhaust duct depends on the operation mode of air conditioner. When
the air conditioner is in automatic and cool mode, it is necessary to install the exhaust
duct, but when the air conditioner is in Fan or Dehu mode, it is unnecessary to install the
exhaust duct.
Users can properly compress or stretch the exhaust duct according to the usage
requirements.Do not arbitrarily extend or bend the exhaust duct.
I
nstall drain hose in Dehu mode.
In Dehu mode, a drain hose should be connected to the
continuous drain outlet at the upper side of the back of the machine.
1. Unplug the rubber plug from the continuous drain outlet at the upper
side of the back of the machine.
2. Insert one end of the drain hose into the upper continuous drain outlet.
3. Connect the other end of the drain hose into a sewer or other container.
Install water full protective drain hose in drainage mode.
In drainage mode, a drain hose should be connected to the continuous drain
outlet at the lower side of the back of the machine.
1. Unplug the rubber plug from the continuous drain outlet at the lower side
of the back of the machine.
2. Insert one end of the drain hose into the lower continuous drain outlet.
3. Connect the other end of the drain hose into a sewer or other container
Note: Connect the drain hose as required to avoid water full protection.
