Schematic diagram of overall product installation
7. Open the window where the
exhaust duct, window partition
and other components need to
be installed.
Figure 7
9. Install the inner joint of the
exhaust duct to the bayonet
on the back of the air conditioner,
and slide it from right to left to
tight fit.
Figure 9
8. Install the exhaust duct, window
partition and other components
on the window, and close the
window in the direction of arrow
to press the window partition
component.
10. As shown in Figure 14, the equipment
is assembled.
11
Figure 8
Figure 10
