Electric Work
WARNING:
BEFORE PERFORMING ANY ELECTRICAL OR WIRING WORK, TURN OFF THE MAIN
POWER TO THE SYSTEM.
Electronic Type
Power
Supply
NOTE: Please strictly follow the wiring label attached to the machine for all wiring
wiring diagram on the purchased unit. The above wiring diagram is a simplified
version for preliminary illustration purposes only.
Display
L/AC L/L1/L-IN
N/AC N/L2/N-IN
Main Control
6
Compressor
Fan Motor
Other
