Timer Functions (cont.)
T imer on
Continue
to press
TIMER ON
or
TIMER OFF
until desired
time is
reached.
1
2
TIMER ON
TIMER ON
5
6
TIMER OFF
TIMER OFF
Example: Set the unit to turn on after 6 hours, operate for 2 hours, then turn off
(see the figure below)
Remote display
Timer On
T
3. Wait 2 seconds, then the TIMER OFF function will be
activated. The digital display on the remote control will
then return to the temperature display.
NOTE
When setting the TIMER ON or TIMER OFF functions,
the time can be adjusted up to 10 hours in 30-minute
increments with each press. After 10 hours, increments
change to 1 hour up to a maximum of 24 hours. The
timer will reset to zero after 24 hours. Either function
can be turned off by setting the timer to "0.0h."
3
X12
7
X16
Timer
Timer is set
Starts
to turn ON
6 hours after
current time
Timer is set
to turn OFF
Current
8 hours after
Time 1PM
current time
4
Setting both TIMER ON and
TIMER OFF at the same time
sec
Note that the time periods set
for both functions refer to the
hours following the current time.
For example, if the current time
is 1:00 PM and the unit is set to
turn on automatically at 7:00 PM
and operate for 2 hours, it will
8
turn off automatically at 9:00 PM.
sec
Do the following (side figure):
4PM
5PM
2PM
3PM
6 hours later
8 hours later
31
Unit turns
Unit turns
ON
OFF
6PM
7PM
8PM
9PM
