13.5.1 Creating a New Internet Service based on the Default
HTTP
Step 1.
In this example it is assumed that there is a web server running on a
computer, and that web server is configured to use a non-standard web
port. Normally a web server would serve TCP/IP port 80, but in this
example it has been configured to serve port 8000. To enable
connections to this server from the workstations you will have to create a
new service. The standard HTTP service does not work here because we
are not using the standard HTTP port any more. This new service is
"HTTP port 8000" and it is based on the default "HTTP" service.
1. Select the subdomain for which you want to create the new service in
the Policy Domains tab.
2. Go to the Settings tab and open the Firewall Services page. This
page contains the Firewall Services Table.
3. Click the Add button to start the Firewall services wizard.
Service Name
1. Define a unique name for the service in the Service name field; you
cannot have two services with the same name. For example, HTTP
port 8000.
2. Enter a descriptive comment for the service in the Service comment
field. The comment will be displayed in the Firewall Services Table.
