SMC Networks VBAE10- 02 Series Operation Manual page 6

Model
Fluid
Pressure increase ratio
Max. flow rate
Outlet pressure range
Inlet pressure range
Proof pressure
Port size (IN, OUT)
OUT side gauge port
Tank connection port (with
*2
plug)
Ambient and fluid
temperatures
Installation
Lubrication
Weight
*1)The gauge ports are Rc thread type regardless of the thread type indication.
*2)The tank connection port cannot be used for applications other than the
connection with VBAT.
Warning
!
1. Warning concerning abnormal outlet pressure
● If there is a likelihood of causing an outlet pressure drop due to unforeseen
circumstances such as equipment malfunction, thus leading to a major problem,
take safety measures on the system side.
● Because the outlet pressure could exceed its set range if there is a large
fluctuation in the inlet pressure, leading to unexpected accidents,
take safety measures against abnormal pressures.
2.Specifications
230L/min(ANR)
(IN=OUT=0.5MPa)
*1
3．Design
VBAE10
Compressed air
1.7 times (Fixed)
0.3 to 1.2MPa
0.2 to 0.7MPa
1.8MPa
1/4
Rc1/8
1/4
2 to 50℃(No freezing)
Horizontal, Vertical
Grease (Non-lube)
1.2kg
5
VBAE20
1000L/min(ANR)
(IN=OUT=0.5MPa)
1/2
1/2
5.0kg
