SMC Networks VBAE10- 02 Series Operation Manual page 14

● Replacement Parts: Kit No.
Place an order with the following applicable kit number.
Model
Kit no.
The kit includes the following parts and a grease pack.
Model
No.
Description
1
2
3
4
5
6
7
- Check valve assembly
- Pilot valve assembly
-
-
-
※The grease pack has 10 g of grease.
※Make sure to refer to the procedure for maintenance.
※For details on the replacement parts kit, refer to the procedure for
maintenance.
11．Replacement Parts
VBAE10
KT-VBAE10-1
Piston seal
Tube gasket
Rod seal
O-ring
Silencer
Flat head screw
Switching valve
Gasket
Pilot silencer
Grease pack
KT-VBAE20-1
VBAE10
Quantity
1 large, 2 small
2 large, 2 small
11
-
13
VBAE20
VBAE20
2
2
4
2
4
2
6
4
1
