SMC Networks VXFC06D Operation Manual

Valve controller
Hide thumbs Also See for VXFC06D:

Advertisement

Quick Links

PRODUCT NAME
Valve Controller
MODEL / Series / Product Number
VXFC06D
VXFC10D
VXFC06D-6
VXFC10D-6
文書 VXF****-OML0001-A

Advertisement

loading
Need help?

Need help?

Do you have a question about the VXFC06D and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Networks VXFC06D

  • Page 1 文書 VXF****-OML0001-A PRODUCT NAME Valve Controller MODEL / Series / Product Number VXFC06D VXFC10D VXFC06D-6 VXFC10D-6...
  • Page 2: Table Of Contents

    Contents 1. Safety Instructions ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P2-5 2. Specifications ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3. Name of Parts ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P7-8 4. Wiring ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 5. Description of operation ・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P10-11 6. Cascade connection ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P12-13 7. Temporary stop operation ・・・・・・・・・・・・・・・・・・・・・・・・・ P14-17 1...
  • Page 3: Safety Instructions

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 4 Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
  • Page 5: Specifications

    Specifications Warning 1. Confirm the specifications. If the voltage or temperature are outside the specification range, it may cause destruction, malfunction,electric shock or fire. 2. Confirm the specifications of the connecting valve Check that the electrical specification of the valve; rated voltage, leakage current, etc. conform to the specifications of the controller.
  • Page 6 Wiring Mounting Warning 1. Check the terminal number when wiring. Incorrect wiring can lead to controller failure and malfunction. Please check the terminal number before wiring. 2. Make sure that no excessive force is applied to the lead wires. Broken lead wires will result if bending stresses or tensile forces are applied to the lead wires. 3.
  • Page 7 2. Specifications Table 1 Specifications Product No. VXFC06D VXFC10D VXFC06D-6 VXFC10D-6 Number of outputs Common 6 in 1 10 in 1 6 in 1 10 in 1 Common common common common Power supply voltage 12VDC ±5% 24VDC to 48VDC ±5%...
  • Page 8 (3) Power supply terminal block (M4 terminal block) Connect to DC+ and DC- within the range of DC24 to 48V. (VXFC06D-6,VXFC10D-6:DC12V) Connected voltage becomes the output voltage to valve. Also, connect earth ground with resistance of 100 ohms or less to FG.
  • Page 9 (8) Output terminal block (M3 terminal block) Output terminal block for cascade trigger signal. Electrical Standard: O/C DC5V 25mA or less (9) Dip switch for setting cascade or temporary stop. Operation is changed by the combination of the switches. Operating conditions: Cascade base Cascade remote Temporary stop (external power)
  • Page 10: Wiring

    4. Wiring 1) Power input Fig. 2. Wiring diagram (1) Make sure the power switch is off. If Switch is ON Turn the switch to OFF. (2) Connect 12,24 to 48VDC to the terminal block. (3) Connect the earth ground (resistance of 100 ohms or less) to the power terminal block (FG). 2) Valve output Fig.
  • Page 11: Description Of Operation

    5. Description of operation 1. Check the wiring before supplying power. 1) Number of output Set the rotary switch for output setting to the number of valves to be used. (0 indicates 10 outputs) Setting is read when powered or one cycle is completed. ①...
  • Page 12 3) Time setting Set the time to output to the valve (ON time) and the pause time (OFF time) to the next output. ※The above 1) to 3) can be changed even after power is on, but time cannot be set during operation.
  • Page 13: Cascade Connection

    There are only outputs up to 10 points (6 points in the case of VXFC06A) on a single board. However, it is possible to increase the output points by cascading (multiple board connection). VXFC06D and VXFC10D can be cascaded to create a 16-point output, and it is possible to increase to any output points by combining boards.
  • Page 14 Ⅲ. Example for cascade connection 1) Setting Cascaded board: 3 pcs. Setting 1st. board 2nd board 3rd. board Cascading Base Remote Remote Output setting 3 output 2 output 3 output Base Remote Remote 2) Operation sequence The sequence of the above setting is shown below. 2) Operation seqence Please see the following sequence under above setting.
  • Page 15: Temporary Stop Operation

    7. Temporary stop operation 7-1. When an external power supply is used I. Setting of DIP switch for temporary stop. 1) DIP switch setting Change the DIP switch as shown below. Operating conditions: Temporary stop Fig. 16 Ⅱ.How to connect (1)Switch contact, relay contact output Fig.
  • Page 16 (2) Transistor output Fig. 18 Temporary stop operation : Transistor OFF Re-Start operation: Transistor ON (3) Open collector output Fig. 19 Temporary stop operation: Open collector OFF Re-Start operation: Open collector ON 15...
  • Page 17 7-2 When an internal power supply is used I. Setting of DIP switch for temporary stop. 1) DIP switch setting Change the DIP switch as shown below. Operating conditions: Temporary stop Fig. 20 II. How to Connect (1) Connect a switch with OUT1 on one side and with IN1 on the other. Fig.
  • Page 18 7.3 Sequence when temporary stop is operating 1) Operation sequence The sequence of a temporary stop is shown below. When the Switch is turned ON the temporary stop operation begins. When the switch is turned OFF the operation stops. Operation starts from the next output when the switch is ON again. When the switch is turned OFF during the output, the operation stops after completing the output, and the operation stops until it is in the ON status.
  • Page 19 Revision A:complete revision 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2021 SMC Corporation All Rights Reserved 18...
