UNIS CARNIVAL SHOT T-482 Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
(Prize Version)
IMPORTANT
To UNIS Parts And
Service/Manuals
Operation Manual
Notice: Check
www.unispartsandservice.com/manuals
for current manuals and updates.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CARNIVAL SHOT T-482 and is the answer not in the manual?

Questions and answers

Related Manuals for UNIS CARNIVAL SHOT T-482

Summary of Contents for UNIS CARNIVAL SHOT T-482

  • Page 1 (Prize Version) IMPORTANT To UNIS Parts And Service/Manuals Operation Manual Notice: Check www.unispartsandservice.com/manuals for current manuals and updates.
  • Page 2 Carnival Shot GMP(Prize) Manual WE ARE HERE TO ASSIST For parts and service Have Questions? Contact us! UNIS SERVICE CENTER Tel: 972-241-4263 Email: service@unispartsandservice.com www.unispartsandservice.com When contacting Service, you will need the following information and the name of your authorized distributor.

  • Page 3: Table Of Contents

    Carnival Shot GMP(Prize) Manual CONTENT IMPORTANT SAFETY INSTRUCTIONS ................ 3 1. SPECIFICATIONS ...................... 5 2. CONTENTS OF THE ACCESSORY KIT ..............6 3. PART NAME ......................7 4. SET UP & INSTALLATION ..................8 5. HOW TO PLAY ......................13 6. GAME OPTION ......................15 7.

  • Page 4: Important Safety Instructions

    Carnival Shot GMP(Prize) Manual Thank you for purchasing Carnival Shot GMP(Prize). We hope you enjoy the product. This manual contains valuable information about how to operate and maintain your game machine properly and safely. It is intended for the owner and/or personnel in charge of product operation.
  • Page 5 Carnival Shot GMP(Prize) Manual Use the following safety guidelines to help ensure your own personal safety and to help protect your equipment and surrounding environment from potential damage. This product is an indoor game machine. Do not install outdoors. Avoid installing in the following places to prevent fire, electric shock, injury and/or machine malfunctioning: ...

  • Page 6: Specifications

    Carnival Shot GMP(Prize) Manual 1. SPECIFICATIONS Rated power supply: AC110V 50/60Hz; AC220V 50/60Hz; Min. Power consumption: 400W Max. Power consumption: 450W Dimension: H93.65×W56.42×D56.1 in H2378.7×W1433 ×D1425 mm Model No: T-482 Part No.: C169 NOTICE : After turning off the game, please wait at least 1 minute before restarting again.

  • Page 7: Contents Of The Accessory Kit

    Carnival Shot GMP(Prize) Manual 2. CONTENTS OF THE ACCESSORY KIT Open the package and make sure all the items are included: 1. Following accessories Part No. Code No. Name Picture C169-1601-00 2.53.00171002 171A key C169-1602-00 2.53.00172002 171B key Power cord C169-1604-00 2.33.01.000001 10A/250V 1.8M...

  • Page 8: Part Name

    Carnival Shot GMP(Prize) Manual 3. PART NAME Key Components Marquee Assembly Speaker Display Prize track Gun assy. Coin mech. Prize out 05/08/2025...

  • Page 9: Set Up & Installation

    Carnival Shot GMP(Prize) Manual 4. SET UP & INSTALLATION NOTICE We do not recommend using power tools as they may cause damage. This product is an indoor game machine. Do not install outdoors.  Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid. ...
  • Page 10 Carnival Shot GMP(Prize) Manual 4.3 Play Zone This machine requires space for playing and for maintenance as shown below. Leave space around the game upon installation: Service area: 20 in Service area Play area NOTICE Your unit must be leveled to operate properly. 05/08/2025...

  • Page 11: Machine Installation

    Carnival Shot GMP(Prize) Manual 4.4 Machine Installation Step 1 Lift the Marquee assy. Utilize screws to secure. Connect the connectors. Marquee assy. Step 2 Loosen screws to remove L&R front side board. Unplug the connectors. L&R front side board 05/08/2025...
  • Page 12 Carnival Shot GMP(Prize) Manual Step 3 Take the Prize cover up. Step 4 Adjust the position of the prize bucket by grasping the handle (the red square shows the position of the handle, which are normally horizontal and will rotate out of the drawer by gently pressing on the edges).
  • Page 13 Carnival Shot GMP(Prize) Manual 4.5 Card Reader Installation Safety Notice Take precaution to assure that all wiring voltages are confirmed prior to installation of card reader. All warranties are void if not properly installed resulting in logic board damage. Important: This game is pre-wired to AAMA standards. It is highly recommended to utilize this wiring for Card reader installation.

  • Page 14: How To Play

    Carnival Shot GMP(Prize) Manual 5. HOW TO PLAY 5.1 Insert coins/tap/swipe card to play. 5.2 Select Scene. Utilize Gun to select, press trigger to confirm. 5.3 Select Game mode. Utilize Gun to select, press trigger to confirm. 05/08/2025...
  • Page 15 Carnival Shot GMP(Prize) Manual 5.4 Aim at target and shoot to win score. 05/08/2025...

  • Page 16: Game Option

    Carnival Shot GMP(Prize) Manual 6. GAME OPTION 6.1 Adjustment button instruction Open the coin door and there is a meter panel. Press Settings button to enter into the setting menu. Settings Test Reset 6.2 Setting menu 6.2.1 Main menu Options Options Game Reset Game Setting...
  • Page 17 Carnival Shot GMP(Prize) Manual Options Adjustment Value Coin Mode Insert Coins_Tap/Swipe Card_Insert Coins & Tap/Swipe Card Prize Bar Percentage/Score 1P Gun Shake 2P Gun Shake Back 6.2.2 Game Setting(Prize) Options Adjustment Value Prize Mode Prize Game Time 30s-30mins Coins Per Game 1-10 Scene/Play 0-99...
  • Page 18 Carnival Shot GMP(Prize) Manual Options Adjustment Value Prize Settings Game Volume 0-10 Demo Volume 0-10 Continue Time(s) 1-60 Gun Calibration Insert Coins_Tap/Swipe Card_Insert Coins & Coin Mode Tap/Swipe Card Prize Bar Percentage/Score 1P Gun Shake 2P Gun Shake Back 6.2.2.1 Prize Settings(Prize&Ticket) Options Adjustment Value Instructions...
  • Page 19 Carnival Shot GMP(Prize) Manual 6.2.2.2 Cost Settings (Cost change will generate new bookkeeping record) Options Adjustment Value Instructions N coins Per Play 0.1-100 Coins N coins /Prize 0.1-200 Coins Back Note: Change above parameters only when cost changes! If need to revise prize payout related setup, please go to “Prize Setting” option.
  • Page 20 Carnival Shot GMP(Prize) Manual 6.2.4 I/O Input Test Options Options Options 1P Insert Coin Prize Feedback 1 OFF Prize Feedback 10 OFF 2P Insert Coin Prize Feedback 2 OFF Prize Feedback 11 OFF 1P Start Button Prize Feedback 3 OFF Prize Feedback 12 OFF 2P Start Button Prize Feedback 4 OFF...
  • Page 21 Carnival Shot GMP(Prize) Manual 6.2.8 Time Setting Options Year Month Hour(24) Minute Second Back&Save Back 05/08/2025...

  • Page 22: Troubleshootings

    Contact with UNIS Service. Turn on power SW again. If appeared Circuit protector make power SW again and again, machine has Power off in off state. anomaly. Please contact with UNIS Service. Card reader not The connector is loose. Check connector. working Card reader fault.
  • Page 23 Carnival Shot GMP(Prize) Manual If you see following error signs showing on the display, please try the recommended action. Display Possible Cause Recommended action Check and reconnect the The connection part of the loose ports of the PC or IO IO board and PC are loose.
  • Page 24 Carnival Shot GMP(Prize) Manual 7.2 System Recovery Operation (NOTE: Do not disconnect power during this process.) 1. Turn off the game. Remove recovery stick from the machine. (Note: This process may take up to 60 minutes) Insert the recovery stick into the port at the back of the computer. 2.

  • Page 25: Maintenance & Inspection

    Carnival Shot GMP(Prize) Manual 8. MAINTENANCE & INSPECTION 8.1 Safety Check Check the points listed before operating the machine. These checks are necessary for safe machine operation: 1. Test game before operation each day. 2. Conduct monthly routine checks of game components to ensure good working condition.

  • Page 26: Overall Construction

    Carnival Shot GMP(Prize) Manual 9.OVERALL CONSTRUCTION 9.1 General Assembly Part No. Code No. Name Version Qty C169-0001-00 202.4.2407.038 Wiring tube bracket V1.1 C169-0002-00 2.51.02.040026 AL prize area connect bracket V1.1 05/08/2025...

  • Page 27: Monitor Assembly

    Carnival Shot GMP(Prize) Manual 9.2 Monitor Assembly Part No. Code No. Name Version Qty C169-0101-00 202.4.2407.039 Connect plate V1.1 C169-0103-00 206.4.2407.015 Monitor glass V1.1 C169-0106-00 202.4.2407.040 Side bottom plate V1.1 C169-0107-00 202.4.2407.041 Front bottom plate V1.1 C169-0110-00 206.4.2407.018 Monitor foam(v) V1.1 C169-0111-00 206.4.2407.019 Monitor foam(h)
  • Page 28 Carnival Shot GMP(Prize) Manual Part No. Code No. Name Version Qty 21 C169-0102-00 2.60.00042000B Wiring box V1.1 22 C169-0104-00 2.60.00055000 Dongle plate V1.1 23 C169-0105-00 2.60.00064000 Recovery stick fixing plate V1.1 24 C169-0109-00 202.1.1605.043 Adapter plate V1.1 9.3 Marquee Part No. Code No.
  • Page 29 Carnival Shot GMP(Prize) Manual 9.4 Monitor Wooden Case 05/08/2025...
  • Page 30 Carnival Shot GMP(Prize) Manual Part No. Code No. Name Version Qty C169-0201-00 203.4.2407.076 L Side board V1.1 C169-0202-00 203.4.2407.077 Monitor cabinet front board V1.1 C169-0203-00 203.4.2407.078 R Side board V1.1 C169-0204-00 203.4.2407.079 Power board V1.1 C169-0205-00 203.4.2407.080 Inner Top board V1.1 C169-0206-00 203.4.2407.081 Base board...
  • Page 31 Carnival Shot GMP(Prize) Manual 9.5 Panel Assembly Part No. Code No. Name Version Qty C169-0401-00 202.4.2407.051 Coin box bracket V1.1 C169-0402-00 2.63.00.000004 Hinge plate V1.1 C169-0403-00 205.4.2407.104 Prize out plastic R V1.1 C169-0404-00 202.4.2407.041 Side long protect plate V1.1 C169-0405-00 202.1.2304.220 Counter bracket V1.1...
  • Page 32 Carnival Shot GMP(Prize) Manual 9.6 Panel Wooden Case Part No. Code No. Name Version Qty C169-0501-00 203.4.2407.095 Panel R side board V1.1 C169-0502-00 203.4.2407.097 Panel L side board V1.1 C169-0503-00 203.4.2407.107 R front slanting board V1.1 C169-0504-00 203.4.2407.109 Panel R front board V1.1 C169-0505-00 203.4.2407.108...
  • Page 33 Carnival Shot GMP(Prize) Manual 9.7 Prize Channel Part No. Code No. Name Version Qty C169-0901-00 206.4.2407.025 Prize cover PET V1.1 C169-0902-00 202.4.2407.059 Flip lock plate V1.1 C169-0114-00 202.4.1914.013 Hinge plate V1.1 C169-0903-00 202.4.2407.060 Flip position shaft plate V1.1 C169-0904-00 202.4.2407.061 L flip side plate V1.1 C169-0905-00 202.4.2407.062...
  • Page 34 Carnival Shot GMP(Prize) Manual 9.8 Prize Channel Wooden Case Part No. Code No. Name Version Qty C169-1001-00 203.4.2407.132 Prize area base board V1.1 C169-1002-00 203.4.2407.133 Prize area back board V1.1 C169-1004-00 203.4.2407.134 Prize bracket base board V1.1 C169-1005-00 203.4.2407.135 Prize bracket back board V1.1 C169-1006-00 203.4.2407.136 Prize bracket blcok board V1.1...
  • Page 35 Carnival Shot GMP(Prize) Manual 9.9 L Prize Hooper Part No. Code No. Name Version Qty C169-1201-00 203.4.2407.138 L prize hopper base board V1.1 C169-1202-00 203.4.2407.139 L prize hopper L slanting board V1.1 C169-1203-00 203.4.2407.140 L prize hopper R slanting board V1.1 C169-1204-00 203.4.2407.141...
  • Page 36 Carnival Shot GMP(Prize) Manual 9.11 L Prize Box Part No. Code No. Name Version Qty C169-0601-00 203.4.2407.025 Prize box R side board V1.1 C169-0602-00 203.4.2407.026 Prize box base board V1.1 C169-0701-00 203.4.2407.045 L Prize box R side board V1.1 C169-0604-00 203.4.2407.028 Prize box back board V1.1 C169-0605-00 203.4.2407.029...
  • Page 37 Carnival Shot GMP(Prize) Manual 9.13 Coin Box Frame Part No. Code No. Name Version C169-1701-00 203.4.2407.047 Coin box base board V1.1 C169-1702-00 203.4.2407.048 Coin box side board V1.1 C169-1703-00 203.4.2407.049 Coin box top board V1.1 C169-1704-00 203.4.2407.050 Coin box back board V1.1 9.14 Gun Placement Bracket Part No.
  • Page 38 Carnival Shot GMP(Prize) Manual 9.15 Woofer Part No. Code No. Name Version C169-0301-00 203.4.2407.072 Woofer base board V1.1 C169-0302-00 203.4.2407.073 Woofer side board V1.1 C169-0303-00 203.4.2407.074 Woofer cover board V1.1 C169-0304-00 203.4.2407.075 Woofer Up&down board V1.1 05/08/2025...
  • Page 39 Carnival Shot GMP(Prize) Manual 9.16 Decals 05/08/2025...
  • Page 40 Carnival Shot GMP(Prize) Manual Part No. Code No. Name Version Qty C169-1529-00 205.4.2407.117 R inner side decal V1.1 C169-1530-00 205.4.2407.118 L inner side decal V1.1 C169-0801-00 205.4.2407.101 LOGO plastic V1.1 C169-1526-00 205.4.2407.114 Prize area cover decal V1.1 C169-1524-00 205.4.2407.112 Prize area L&R decal V1.1 C169-0417-00 205.4.2407.103...
  • Page 41 Carnival Shot GMP(Prize) Manual 05/08/2025...
  • Page 42 Carnival Shot GMP(Prize) Manual Part No. Code No. Name Version Qty C169-1503-00 2.56.00.000036 High voltage warning decal(s) V1.1 C169-1528-00 205.4.2407.116 Counter decal set V1.1 C169-1534-00 205.4.2407.135 220V nameplate V1.1 C169-1533-00 205.4.2407.134 110V nameplate V1.1 C169-1509-00 2.56.00.000120 AAMA warning decal V1.1 C169-1510-00 2.56.00.000121 Adapter decal...

  • Page 43: Electrical Components

    Carnival Shot GMP(Prize) Manual 9.17 Electrical Components 05/08/2025...
  • Page 44 Carnival Shot GMP(Prize) Manual Part No. Code No. Name Version 1 C169-1427-00 2.20.02.020090 2835 pink light strip V1.1 61.02 in (1550mm) 2 C169-1427-00 2.20.02.020090 2835 pink light strip V1.1 51.18 in (1300mm) C169-1426-00 2.20.02.020062 2835 blue light strip V1.1 51.18 in (1300mm) 3 C169-1427-00 2.20.02.020090 2835 pink light strip V1.1...
  • Page 45 Carnival Shot GMP(Prize) Manual Part No. Code No. Name Version C169-1442-00 2.16.03.000076 Adapter V1.1 C169-1418-00 2.28.03.060007 Amplifier V1.1 C169-1432-00 2.33.01.040051 DC power cord V1.1 C169-1434-00 2.33.05.000007 Audio cable V1.1 C169-1413-00 2.17.14.000148G Fuse board V1.1 C169-1404-00 2.16.02.000117 Power supply(12V) V1.1 C169-1405-00 2.16.02.000121 Power supply(24V) V1.1...
  • Page 46 Carnival Shot GMP(Prize) Manual Part No. Code No. Name Version C169-1409-00 2.27.02.050017 V1.1 C169-1410-00 2.27.02.000010 Fan net V1.1 C169-1407-00 2.12.01055010 55'' monitor V1.1 C169-1414-00 2.33.07.000015A DVI cable V1.1 C169-1422-00 2.33.01.010045 Power cord V1.1 05/08/2025...
  • Page 47 Carnival Shot GMP(Prize) Manual Part No. Code No. Name Version C169-1430-00 2.31.00000015 Ticket dispenser V1.1 C169-1429-00 297.9.0700002 Ticket convert board V1.1 Part No. Code No. Name Version C169-1431-00 2.30.00000005 Meter V1.1 C169-1419-00 2.24.03.000001 Knob V1.1 C169-1420-00 297.9.1400001 POT board V1.1 C169-1401-00 2.24.02.010002 Red button...
  • Page 48 Carnival Shot GMP(Prize) Manual Part No. Code No. Name Version Qty C169-1436-00 2.11.02.000155 V1.1 C169-1414-00 2.33.07.000015A DVI cable V1.1 C169-1434-00 2.33.05.000007 Audio cable V1.1 C169-1437-00 2.33.04.000028 Extendsion cable V1.1 C169-1412-00 2.33.04.000100 Extendsion cable(0.5m) V1.1 C169-1422-00 2.33.01.010045 Power cord V1.1 C169-1415-00 2.11.09.000029 Dongle V1.1 05/08/2025...
  • Page 49 Carnival Shot GMP(Prize) Manual Part No. Code No. Name Version Qty C169-1440-00 208.4.2407.005 Gun set(included gun&board) V1.1 C169-1433-00 2.14.12.020004 USB-serial port cable V1.1 Part No. Code No. Name Version C169-1408-00 2.32.01000001A Filter V1.1 C169-1439-00 2.33.02.000001 Network port V1.1 C169-1416-00 2.19.01.000004A Fuse V1.1 C169-1411-00...
  • Page 50 Carnival Shot GMP(Prize) Manual Part No. Code No. Name Version BG5050W white light 27.55 in C169-1428-00 2.20.02.015019 V1.1 strip (700mm) BG5050W white light 27.55 in C169-1428-00 2.20.02.015019 V1.1 strip (700mm) C169-0908-00 299.4.2407.001 Track V1.1 05/08/2025...
  • Page 51 Carnival Shot GMP(Prize) Manual Gun set(included gun&board,Cable) Part No. Code No. Name Version C169-1444-00 208.4.2407.006 Camera V1.1 C169-1445-00 208.4.2407.004 Gun IO board V1.1 C169-1446-00 208.4.2407.001 Blue gun V1.1 C169-1447-00 208.4.2407.002 Pink gun V1.1 C169-1448-00 208.4.2407.003 Gun cable set V1.1 C169-1449-00 208.4.2407.007 Gun laser light V1.1...
