AMP Research PowerStep 75154-01A-B Installation Manual

Chevrolet silverado1500/gmc sierra 1500-double/crew cab 2014-18, chevrolet silverado hd/gmc sierra hd-double/crew cab excludes diesel engine 2015-19
Hide thumbs Also See for PowerStep 75154-01A-B:

Advertisement

Quick Links

Download this manual
APPLICATION
Chevrolet Silverado1500 / GMC Sierra 1500 - Double Cab
Chevrolet Silverado1500 / GMC Sierra 1500- Crew Cab
Chevrolet Silverado HD / GMC Sierra HD - Double Cab
Chevrolet Silverado HD / GMC Sierra HD- Crew Cab
* Modification required to running board assembly. See Item 1 on page 3.
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents:
6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.
Printed in USA.
www.amp-research.com
I N S T A L L A T I O N G U I D E
®
1/12
*
2014-18
2014-18
*
2015-19
(excludes diesel engine)
2015-19
(excludes diesel engine)
INSTALLATION TIME
Professional installation recommended
1 2 3
q Safety goggles
q Measuring tape
q Flat blade screwdriver
q Power Drill
q 9/32" drill bit
q 13 mm socket
q 10 mm socket
q 7 mm socket
q Ratchet wrench and extension
q 13mm end wrench
q Wire crimpers
q Wire stripper / cutter
q
3 /16" hex key wrench (allen wrench)
q
5 mm hex key wrench (allen wrench)
q
4mm hex key wrench ( allen wrench )
q
Electrical tape
q
Weather proof caulking (silicone sealer)
q
Silicone spray
5-Year Limited Warranty
TM
AMP Part #
75154-01A-B
75154-01A-B
75154-01A-B
75154-01A-B
3-5 Hours
SKILL LEVEL
4
4= Experienced
TOOLS REQUIRED
WARRANTY
IM75154 rev 10.14.21

Advertisement

loading
Need help?

Need help?

Do you have a question about the PowerStep 75154-01A-B and is the answer not in the manual?

Questions and answers

Related Manuals for AMP Research PowerStep 75154-01A-B

Summary of Contents for AMP Research PowerStep 75154-01A-B

  • Page 1 AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents: 6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.
  • Page 2 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C INSTALLATION GUIDE Attaching motor to Linkage assembly The motors must be attached to the Linkage assemblies before continuing the installation process.
  • Page 3 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Note: Some Applications require modification. Application Cut Length Crew Cab 79”...
  • Page 4 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Hex Bolt with Conical Nut with Conical Hex Bolt with Conical U-nut Washer...
  • Page 5 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C 1500 MODELS ONLY! Front Idler Linkage: Thread supplied bolt (10) in about half way into the first sheetmetal tab / hole from Install U Nut (13) into position just forward of front.
  • Page 6 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Route long end of wire harness above engine and Pull up front door sill plate covers as shown.
  • Page 7 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Using a 7mm socket remove the 6 screws that secure Pry all panel fasteners loose.
  • Page 8 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Route trigger wire into the door. Poke hole through Tape red wire to (grey with black wire on driver side and tan with white stripe on passenger side).
  • Page 9 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Re-attach window seal. Ensure seal is pushed Replace plug and door latch cable.
  • Page 10 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Use supplied red wire and feed through accordian Feed wire to front sill area.
  • Page 11 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Remove door latch cable from door panel. Route trigger wire into the door.
  • Page 12 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Reinstall fuse. Check that all doors activate the Power Step and the LED Lights work when doors open and close.
  • Page 13 • Registration helps us keep you up to date on product information and offers To view other Amp Research products that may be offered for your vehicle. Please visit: www.amp-research.com Rev 01.05.21...
  • Page 14 5-YEAR LIMITED WARRANTY AMP RESEARCH warrants this product to be free from defects in material and workmanship for FIVE (5) YEARS FROM DATE OF PURCHASE, provided there has been normal use and proper maintenance. This warranty applies to the original purchaser only.
