Appendix 3 Wire Gauge Reference Sheet
Metric Bare Wire
Diameter (mm)
0.050
0.060
0.070
0.080
0.090
0.100
0.110
0.130
0.140
0.160
0.180
0.200
0.230
0.250
0.290
0.330
0.350
0.400
0.450
0.560
0.600
0.710
0.750
0.800
0.900
1.000
1.250
1.500
2.000
2.500
3.000
Appendix Table 3-1Wire gauge reference sheet
AWG SWG
43 47
42 46
41 45
40 44
39 43
38 42
37 41
36 39
35 /
34 37
33 /
32 35
31 /
30 33
29 31
28 30
27 29
26 28
25 /
24 24
23 23
22 22
21 /
20 21
19 20
18 19
16 18
15 /
12 14
/ /
/ /
31
Quick Start Guide
Bare Wire Cross
2
Section Area (mm )
0.00196
0.00283
0.00385
0.00503
0.00636
0.00785
0.00950
0.01327
0.01539
0.02011
0.02545
0.03142
0.04115
0.04909
0.06605
0.08553
0.09621
0.1257
0.1602
0.2463
0.2827
0.3958
0.4417
0.5027
0.6362
0.7854
1.2266
1.7663
3.1420
4.9080
7.0683
