For the details of connecting explosion-proof flexible tube, see "2.3.3 Connecting the
Explosion-Proof Flexible Tube". For the cable connection, see "2.3.1 Cable Description".
Make sure that the installation surface can withstand at least three times the combined
weight of the bracket and the device to be installed.
No. Description
1 Wall
2 4 screws used to fix the bracket on the wall
Figure 3-7 Cable layout
Table 3-1 Cable layout description
