2.2 Dimensions
The following figure is for reference only, and the actual product shall prevail.
2.3 Cable Connection
2.3.1 Cable Description
When delivered out of factory, the Camera is connected with a composite cable. The cable threads
out from the outlet hole at the Camera rear, and it is 8 m by default. The diameter of the cable is 8.5
mm.
The cables vary with the product models, and the actual cables shall prevail. The manual will
introduce the cables as complete as possible.
Figure 2-3 Dimensions (mm [inch])
