LEFS
Series
Construction
A
i
@2
B-B
Component Parts
No. Description
1 Body
2 Rail guide
3 Ball screw shaft
4 Ball screw nut
5 Table
6 Blanking plate
7 Seal band stopper
8 Housing A
9 Housing B
10 Bearing stopper
11 Return plate
12 Pulley
13 Pulley
11
With lock
q @1 u
@0 !6
B
e
B
w
Body
Table
Material Note
Aluminum alloy Anodized
—
—
—
Aluminum alloy Anodized
Aluminum alloy Anodized
Synthetic resin
Aluminum die-casted Coating
Aluminum die-casted Coating
Aluminum alloy
Aluminum alloy Coating
Aluminum alloy
Aluminum alloy
!9
!8
A-A
t y
r
C-C
!2 !4
!3
No. Description
15 Cover plate
16 Table spacer
17 Motor
18 Motor cover
19 Motor cover with lock
20 Band stopper
21 Dust seal band
22 Bearing
23 Bearing
A
o @0 !1 !5
@3
C
!0
C
D-D
!7
D
D
Material
Aluminum alloy
Aluminum alloy
—
Synthetic resin
Aluminum alloy
Stainless steel
Stainless steel
—
—
Note
Coating
Coating
Anodized
