Electric Actuator/Slider Type
Motor Parallel Type
Reduced in overall length
Parallel
In-line
Length reduction
Size
(mm)
16
80.5
25
75
32
87
40
102.6
∗ Step motor, Stroke: 300 mm
Top surface of table and motor are level.
Workpiece
Table
For in-line
motor
Ball Screw Drive
Size: 16, 25, 32, 40
Step Motor
(Servo/24 VDC)
Servo Motor
(24 VDC)
132.3
Max. work load:
Positioning repeatability: ±
Reduced
dimension
Motor mounting position (mm)
Parallel
In-line
416.5
497
460.5
535.5
495
582
553.4
656
Workpiece
Interference
Motor
Workpiece
Table
LEFS
Series
Type
Type
(60
)
lb
kg
0.02
mm
Reduced in height
Parallel
Reduced
dimension
Length reduction
Size
(mm)
16
6
25
9.5
32
16
40
0
∗ Step motor
Motor mounting position can be selected
from two directions.
Right side
parallel
Size: 25, 32, 40
AC Servo Motor
Type
∗ Not applicable to UL.
Improved high speed transfer ability Max. speed:
High acceleration/deceleration:
¡Pulse input type
(For LECSA/B)
¡With internal absolute encoder
¡Compatible with CC-Link and SSCNET
INFORMATION
RoHS
In-line
Motor mounting position (mm)
Parallel
In-line
40
46
48
57.5
63
79
68
68
Left side parallel
1,000
mm/s
20,000
mm/s
2
(For LECSB/C/S)
.
#
12-E601
