SMC Networks LEFS Series Manual page 103

LEJS
Series
Dimensions: Ball Screw Drive
LEJS63
Body mounting
reference plane
M4 x 0.7 depth 8
25
(F.G. terminal)
49.5
63.5
73
39
13
Note 1) Distance within which the table can move when it returns to origin. Make sure a workpiece mounted on the table does not interfere with the workpieces and
facilities around the table.
Note 2) The Z-phase first detecting position from the stroke end of the motor side
Note 3) Auto switch magnet is located in the table center.
Model
LEJS63V -300 -
LEJS63V -400 -
LEJS63V -500 -
LEJS63V -600 -
LEJS63V -700 -
LEJS63V -800 -
LEJS63V -900 -
LEJS63V -1000 -
LEJS63V -1200 -
LEJS63V -1500 -
55
4 x M8 x 1.25
depth 12
A
(Table traveling distance)
Stroke
(4)
B
n
x ø6.8
E C
x 200 (=
L
Without lock With lock
656.5 696.5
756.5 796.5
856.5 896.5
956.5 996.5
1056.5 1096.5
1156.5 1196.5
1256.5 1296.5
1356.5 1396.5
1556.5 1596.5
1856.5 1896.5
(172)
ø6H9 (
122
90
+0.030
6H9 ( ) depth 7
0
Encoder Z-phase detecting
position Note 2)
L
B
Note 1) 186 ( : With lock/226)
(64)
(66)
2±1
30
ø8H9 (
200
D
) 25
A B
306 370
406 470
506 570
606 670
706 770
806 870
906 970
1006 1070
1206 1270
1506 1570
+0.030
) depth 7
Encoder cable
0
(3.1)
(ø7)
Motor cable
(ø7)
+0.036 ) depth 6
0
n C D
6 1 200
8 2 400
8 2 400
10 3 600
10 3 600
12 4 800
12 4 800
14 5 1000
16 6 1200
18 7 1400
35
[mm]
E
180
80
180
80
180
80
180
80
80
180
