Installation
Installation kit:
x1
Installation template
Material:
For the unit to be securely fixed in such conditions, it is recommended to use:
If the installation surface has different properties, the screws and plastic
anchors must be defined by a qualified installer.
Screws and plastic anchors are not included.
The installation kit has been tested on a concrete wall.
Before the installation, a qualified installer must check that the
wall is in a perfect condition, and which screws and anchors are
suitable for that conditions.
14
x1
Wall Plate
4 x Steel wall screws: DIN 571 Ø5x40
1 x Steel wall screw: DIN 571 Ø5x60
5 x plastic anchors: Ø6x30
CIRCONTROL — eVolve Series — Installation Manual
x1
Sealing washer
