Technical Data
ELECTRICAL SPECIFICATIONS
Power supply
Rated voltage, U
n
Rated insulation voltage, U
Rated impulse withstand voltage,
U
imp
Rated current of the assembly, I
Rated conditional short-circuit
current, I
CC
Earthing system
Frequency
Protection class
PROTECTIONS SPECIFICATIONS
Miniature Circuit Breaker, MCB
(Overcurrent protection)
Residual Current Device, RCD
(Residual current protection)**
Protections included inside the unit.
(*) Equipment to be installed outdoors shall be provided with the Low Temperature
Kit in order to comply with the IEC 61851-1:2017.
(**) RCD Type A is not available for model C63 One.
1P+N+PE / 3P+N+PE
230V AC+/- 10% Single-Phase
400V AC+/-10% Three-Phase
230 V
i AC
4 kV
2 x 32 A
nA
6 kA
TT or TN-S
50 Hz / 60 Hz
Class I
40 A , Curve C, 4 poles (3P + N)
Type A 30 mA + 6 mA DC, 4 poles (3P + N)/
Type B 30 mA, 4 poles (3P + N) (Optional)
21
