Circontrol Post eVolve Series Installation Manual page 13

Dimensions
A
Minimum distances
When installing the unit, respect the minimum distances for maintenance and safety
reasons.
Please comply with your country specifications.
The following image shows how it should be installed.
• Do not install near areas where water or fluids can penetrate into the unit.
• Do not install the unit on unstable terrain.
(*) If Bollard Impact Protector is installed, keep 500 mm as a minimum distance in order to
allow enough space to open the frontal door of the Charge Point for maintenance tasks.
500
50
500
x
*
Measures in mm
09
