RGBlink mini-ISO Quick Start Manual page 6

❺
Five-direction joystick
Audio Adjustment Knob
❻
AFV
Mute
❼
①②③④⑤
❽
T-Bar
www.rgblink.com
● Move the joystick up, down, left and right
○ Adjust the direction of a PTZ when it is being controlled.
○ Adjust the layer position when a layer is being controlled. Tap to
enable the layer scaling and tap again to reset the layer size to full
screen and another tap can reset the layer to the previous size.
Audio Adjustment Knob:
○ The knobs with digital logos are used to adjust the volume of the
input signals HDMI 1~4 (embedded audio). Tap [AFV] to enable the
audio-follow-video function of the current channel.
○ The left bottom knob controls the analog audio input. Tap the
button to mute and tap again to cancel the mute.
○ The right bottom knob is for the program output volume control.
Tap the button to mute and tap again to cancel the mute.
● Press button 1~5 above to switch the dedicated input directly to the
program output.
● Press button 1~5 below to switch the Preview signals according to
the layer selected.
● Press "CUT"to switch between PRE and PGM.
● Press "AUTO"to switch the layer effects between the PRE and PGM.
● Botton unlit: no input signal
● Button lit white: an input source loaded but unselected
● Button lit green: preview output status
● Button lit red: program output status
● Switch manually between the preview and program outputs
according to the selected switching effect.
5
