RGBlink mini-ISO Quick Start Manual page 5

No. Item
❶
ZOOM IN/OUT
Streaming and view
❷
recall button
❸
3.5-inch touch screen
ENTER
❹
MENU
A/B
www.rgblink.com
Front Panel
Description
● Function as focus adjustment and zoom in/out when a PTZ device is
being controlled.
● Adjust the layer size when a layer is selected.
● Tap to turn on/off the streaming.
● S is the shortcut key for layer (PIP) or PTZ control selection. Tap to
illuminate the button and enter layer scaling and layer position
adjustment.
● Ten preview windows by default.
● Tap the screen to start the MENU interface.
ENTER
Tap the button to select and confirm the selection.
MENU
● Tap the button
○ Tap the 10 pre-monitoring windows screen to open the main menu.
○ Tap the menu screen to return to the previous interface and the
main menu with a long press.
○ Tap the main menu to exit the menu interface and enter the 10
pre-monitoring windows screen.
A/B
Tap to select a layer.
4
