Premium Aluminum TV Wall Mount
Instruction Manual
SKU: MOUNT-G400B/W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-g400b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-G400B
Summary of Contents for Vivo MOUNT-G400B
- Page 1 Premium Aluminum TV Wall Mount Instruction Manual SKU: MOUNT-G400B/W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-g400b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
ONLY. Failure to follow instructions may result in damage to TV and/or serious personal injury. Please verify intended mounting location before proceeding. If unsure, please contact us at 309-278-5353 or help@vivo-us.com. DO NOT EXCEED WEIGHT CAPACITY. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 OPTION A: Wood Wall OPTION B: Concrete Wall Using the wall plate on Arm (A), mark drilling Using the wall plate on Arm (A), mark drilling locations. Use of a stud finder is highly locations. Drill 2.4” (60mm) deep holes using a recommended. - Page 4 STEP 3 Remove lower nut from VESA Plate (B) using the Wrench (T-A), and loosen the upper two nuts until 3mm of screw thread is exposed for each one. STEP 4 Mount VESA Extensions (C) to VESA Plate (B) in one of the patterns shown using Carriage Bolts (S-B) and Nuts (S-A), and tighten with Wrench (T-A).
- Page 5 STEP 5 OPTION A: Flat Back Monitor Mount VESA Plate (B) to TV using appropriate Screws (M-A through M-D) with M8 Washers (M-E), making sure the two nuts are facing towards the top of the TV. If needed, Spacers (M-F, M-G) have been provided.
- Page 6 STEP 7 Reinstall lower nut to secure the plate, and tighten all nuts using Wrench (T-A). STEP 8 Adjust gas spring tension using 6mm Allen Wrench (T-C). Turn counter-clockwise to increase lift, and clockwise to decrease. Adjust the tilt joint support using 4mm Allen Wrench (T-B). NOTE: use a large flat-blade screwdriver to tighten the socket set screw if the joint makes a popping noise.
- Page 7 STEP 9 Use built in cable clips to manage cables. Adjust as Desired...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
