- Page 1 Industrial PC EPC/PPC-CM5-070 PN: CS10600RA5070 Content can change at anytime, check our website for latest information of this product. www.chipsee.com...
-
Page 2: Table Of Contents
Contents EPC/PPC-CM5-070 1. Product Overview 2. Ordering Options ® 2.1. Pi CM5 Module 2.2. Operating System 2.3. Optional Features 3. Specifications 4. Power Input 5. Touch Screen 6. Connectivity 6.1. RS232/RS485/CAN 6.2. GPIO Port 6.3. USB Connectors 6.4. LAN 6.5. WiFi & BT Module 6.6. -
Page 3: Epc/Ppc-Cm5-070
EPC/PPC-CM5-070 EPC/PPC-CM5-070 Front View Chipsee Page 3 of 36... -
Page 4: Rear View
EPC/PPC-CM5-070 Rear View Chipsee Page 4 of 36... -
Page 5: Side View
EPC/PPC-CM5-070 Side View 1 Chipsee Page 5 of 36... - Page 6 EPC/PPC-CM5-070 Rear View (Embedded Variant) Chipsee Page 6 of 36...
-
Page 7: Product Overview
® ® The Cortex -A76 Raspberry Pi series EPC/PPC-CM5-070 (PN: CS10600RA5070) is a high- quality industrial Pi PC. This single board computer features a 7” five-point capacitive touch screen with a resolution of 1024 x 600 pixels and brightness of 500 cd/m Raspberry Pi Display. -
Page 8: Ordering Options
® The EPC/PPC-CM5-070 industrial Pi PC does not include the CM5 Raspberry Pi module by default. If you would like to purchase it with a CM5, you can select it at the Chipsee store during the ordering process. Operating System This product comes with a pre-installed Raspberry Pi OS. -
Page 9: Optional Features
Optional Features The EPC/PPC-CM5-070 industrial Pi PC does not include the 3G/4G/LTE modules by default. These modules are optional and can be selected at the Chipsee store during the ordering process. The product has a PCIe Gen 2 × 1 (5Gbps), M.2 M-Key 2230/2242 socket (PCIe 3.0 is possible but experimental for CM5), you can use it with your NVMe SSD or other modules that can fit in the slot and supports the protocol. -
Page 10: Specifications
EPC/PPC-CM5-070 Specifications Specifications The EPC/PPC-CM5-070 industrial Pi PC offers a broad range of performance and connectivity options for scalable integration, providing expandability according to future needs. Some of the key features are listed in the table below. EPC/PPC-CM5-070 ® Raspberry Pi CM5/CM5Lite; BCM2712 Quad(4) Core Cortex-A76 at 2.4GHz... - Page 11 The RS485 circuit controls the Input and Output direction automatically, there’s no need to control it from within the software. The default product without the CM5 does not include a Wi-Fi/BT module. You can include a CM5 that has the Wi-Fi/BT module at the Chipsee store during the ordering process. Chipsee Page 11 of 36...
-
Page 12: Power Input
EPC/PPC-CM5-070 Power Input Power Input The EPC/PPC-CM5-070 industrial Pi PC can be powered by a wide range of input voltages: 9V to 30V DC. There are two types of power input connectors. One is a 3 Pin, 3.81mm screw terminal connector, and the other is a 2.1mm DC input head. - Page 13 EPC/PPC-CM5-070 Power Input For a proper 2.1mm x 5.5mm x 9.5mm DC power connector, refer to the figure below: DC Jack Chipsee Page 13 of 36...
-
Page 14: Touch Screen
Touch Screen Touch Screen The EPC/PPC-CM5-070 industrial Pi PC uses a 5-point capacitive touch with 1mm Armored Glass screen. However, the Raspberry Pi OS supports only One-Point touch. The figure below shows the capacitive touch screen connected to the motherboard via the FPC connector. - Page 15 Use a high-quality Power Adapter Unit (PSU) with low EMR. You can also provide power from a battery. Make sure that the EPC/PPC-CM5-070 Power Input connector (pin 3) is properly connected to the Power System Ground to provide sufficient EMI shielding and eliminate the problem entirely.
-
Page 16: Connectivity
Connectivity Connectivity There are many connectivity options available on the EPC/PPC-CM5-070 industrial Pi PC. It has 2 x USB 3.0 type-A Host, 1 x USB type-C OTG, 1 x Giga LAN (RJ45) Ethernet connector supporting up to 1 Gbps, and 4 x UART and 1 x CAN terminals (RS232/RS485/CAN). - Page 17 EPC/PPC-CM5-070 RS232/RS485/CAN RS232 / RS485 / CAN Pin Definition: /dev/ Pin 6 RS232_2_RXD CPU UART2, RS232 RXD signal ttyAMA1 Pin 5 RS232_2_TXD CPU UART2, RS232 TXD signal /dev/ Pin 4 RS232_0_RXD CPU UART0, RS232 RXD signal, Debug Port ttyAMA0 Pin 3...
- Page 18 EPC/PPC-CM5-070 RS232/RS485/CAN Attention RS485_3 and RS485_5 can control the input and output direction automatically. There’s no need to control it from within the software. The 120Ω match resistor for RS485 is NOT mounted by default. The 120Ω match resistor for CAN is NOT mounted by default. Be sure to mount the match resistor when testing CAN.
-
Page 19: Gpio Port
EPC/PPC-CM5-070 GPIO Port GPIO Port The EPC/PPC-CM5-070 industrial Pi PC has a 10 Pin 3.81mm GPIO Connector, as shown in the figure below. The table below gives details about the definition of every Pin. Attention In order to use the Isolated Output, you need to add an external Isolated Power to the VDD_ISO and GND_ISO. - Page 20 EPC/PPC-CM5-070 GPIO Port GPIO Connector GPIO Connector Pin Definition: Pin Number Definition Description Pin 10 VDD_ISO Isolated Power +5V ~ +24V Input Pin 9 GND_ISO Isolated Ground Pin 8 OUT1 Isolated Output 1 Pin 7 OUT2 Isolated Output 2 Pin 6...
-
Page 21: Usb Connectors
EPC/PPC-CM5-070 USB Connectors USB Connectors There are 2 x USB 3.0 type-A Host, 1 x USB type-C OTG onboard, as shown in the figure below. USB HOST Connectors Attention 1. These two USB host connectors can drive 500mA for each channel at most. - Page 22 EPC/PPC-CM5-070 USB Connectors USB Type-C OTG Connector Warning Be careful not to touch surrounding electronic components accidentally while plugging in USB devices into the embedded Industrial PC version. Chipsee Page 22 of 36...
-
Page 23: Lan
EPC/PPC-CM5-070 The 1 x Giga LAN provides Ethernet connectivity over standardized Ethernet cables as shown in the figure below. The integrated Ethernet interface supports up to 1 Gbps data throughput. These Giga LAN signals come from the CM5 module directly. -
Page 24: Wifi & Bt Module
WiFi & BT Module WiFi & BT Module The default EPC/PPC-CM5-070 without the CM5 does not include a Wi-Fi/BT module. If you include a CM5 that has the Wi-Fi/BT module, the product will have Wi-Fi/BT feature. The product also has an SMA connector for an external WiFi/BT antenna: WiFi+BT Antenna ... -
Page 25: 3G/4G/Lte Module
3G/4G/LTE Module 3G/4G/LTE Module The EPC/PPC-CM5-070 industrial Pi PC is equipped with a mini-PCIe connector that can connect to a 3G/4G/LTE module. The customer will also need a SIM Card Holder and a 3G/ 4G/LTE antenna to ensure 3G/4G/LTE works on the EPC/PPC-CM5-070. SIM card does NOT support hot plug. -
Page 26: M.2 Module
M.2 Module M.2 Module The EPC/PPC-CM5-070 industrial Pi PC has a M.2 slot, it supports NVME m.2 SSD or other m. 2 modules such as an AI compute module. It’s PCIe Gen 2 × 1 (5Gbps), M.2 M-Key 2230/2242 socket. The modules are not included in the product by default. -
Page 27: Camera Connector
EPC/PPC-CM5-070 Camera Connector Camera Connector The EPC/PPC-CM5-070 industrial Pi PC has a 22 Pin Camera Connector. The camera signals come from CAM1. The table below gives details about the definition of every pin. Camera Connector Camera Connector Pin Definition: Pin Number... - Page 28 System +3.3V Power Output, No more than 500mA Current output Table 326 Camera Connector Pin-out Attention The camera connector is supported but not mounted by default. Please contact us when placing an order if you need to use camera on the EPC/PPC-CM5-070. Chipsee Page 28 of 36...
-
Page 29: Tf Card Slot
EPC/PPC-CM5-070 TF Card Slot TF Card Slot The EPC/PPC-CM5-070 industrial Pi PC features 1 x TF Card (micro SD) slot. A slot can address up to 128GB of memory. TF (micro SD) Card Slot Attention The TF card cannot be used for memory extension. It is only used for system boot-up for CM5 LITE model. -
Page 30: Audio Connectors
EPC/PPC-CM5-070 Audio Connectors Audio Connectors The EPC/PPC-CM5-070 industrial Pi PC features some audio peripherals. It has 1 x 3.5mm audio output jack. Also, the EPC/PPC-CM5-070 industrial Pi PC has a miniature 2W internal speaker for audio reproduction, as well as a small buzzer for alarm/notification sounds. -
Page 31: Hdmi Connector
EPC/PPC-CM5-070 HDMI Connector HDMI Connector The EPC/PPC-CM5-070 industrial Pi PC supports 1 x HDMI 2.0 out, can be driven up to 4K 60FPS. Micro HDMI Connector Chipsee Page 31 of 36... -
Page 32: Prog Button
EPC/PPC-CM5-070 PROG Button PROG Button The EPC/PPC-CM5-070 industrial Pi PC has one button for entering usb download mode, as shown in the figure below. When booting with the button being pressed, the Raspberry Pi will boot from the USB connector. You can use this feature to download the OS software to the internal eMMC. -
Page 33: Mounting Procedure
EPC/PPC-CM5-070 Mounting Procedure Mounting Procedure The EPC/PPC-CM5-070 industrial Pi PC can be mounted with 4 x M4 screws, enabling simplified installation onto any standard mounting fixture. CS10600RA5070P You can mount CS10600RA5070P with VESA mounting (guide): 75 x 75 mm, 4 x M4 (6mm) screws. -
Page 34: Mechanical Specifications
EPC/PPC-CM5-070 Mechanical Specifications Mechanical Specifications CS10600RA5070P For CS10600RA5070P, the outer mechanical dimensions are 206 x 135 x 30mm (W x L x H). CS10600RA5070P Technical Drawing CS10600RA5070E For CS10600RA5070E, the outer mechanical dimensions are 190 × 107.8 × 27.7 mm (W x L x Please refer to the technical drawing in the figure below for details related to the specific product measurements. - Page 35 EPC/PPC-CM5-070 CS10600RA5070E CS10600RA5070E Technical Drawing Chipsee Page 35 of 36...
-
Page 36: Disclaimer
If you cannot find the solution you’re looking for, feel free to contact us. Please email Chipsee Technical Support at support@chipsee.com, providing all relevant information. We value your queries and suggestions and are committed to providing you with the assistance you require.
