- Page 1 Industrial PC EPC/PPC-CM4-050 PN: CS12720RA4050 Content can change at anytime, check documentation website for latest information. www.chipsee.com...
-
Page 2: Table Of Contents
6.5. Camera Connector 7. TF Card Slot 8. Audio Connectors 9. Boot DIP Switch 10. Mounting Procedure 10.1. CS12720RA4050E 10.2. CS12720RA4050P 11. Mechanical Specifications 11.1. CS12720RA4050E 11.2. CS12720RA4050P 12. 3D Model 13. Disclaimer 14. Technical Support Chipsee Page 2 of 20... -
Page 3: Epc/Ppc-Cm4-050
EPC/PPC-CM4-050 EPC/PPC-CM4-050 Front View Chipsee Page 3 of 20... - Page 4 EPC/PPC-CM4-050 Rear View Chipsee Page 4 of 20...
- Page 5 EPC/PPC-CM4-050 Front View (Embedded Variant) Chipsee Page 5 of 20...
- Page 6 EPC/PPC-CM4-050 Rear View (Embedded Variant) Chipsee Page 6 of 20...
-
Page 7: Product Overview
Compute Module 4, powered by the Quad Cortex -A72 processor with a processor speed of 1.5GHz. Ordering Options Chipsee products can be customized during the ordering process. The product will be shipped with the pre-installed factory defaults if no extra requirements are specified. The table in the... -
Page 8: Pi Cm4 Module
® The EPC/PPC-CM4-050 industrial Pi PC does not include the CM4 Raspberry Pi module by default. If you would like to purchase it with a CM4, you can select it at the Chipsee store during the ordering process. Operating System This product comes with a pre-installed Debian OS. -
Page 9: Power Input
The default product without the CM4 does not include a Wi-Fi/BT module. You can include a CM4 that has the Wi-Fi/BT module at the Chipsee store during the ordering process. Chipsee designed TF card slots for storage expansion, as the TF card for storage expansion use same pins with WiFi, it can’t be used with WiFi at same time ... -
Page 10: Touch Screen
The EPC/PPC-CM4-050 industrial Pi PC uses a 5-point capacitive touch screen. However, the Debian OS supports only One-Point touch. The figure below shows the capacitive touch screen connected to the motherboard via the FPC connector. Chipsee Page 10 of 20... -
Page 11: Connectivity
2 x USB 2.0 Host, 1 x Type-C, 1 x Channel Giga LAN (RJ45) Ethernet connector supporting up to 1 Gbps, and 4 x UART terminals (RS232/RS485/CAN). RS232/RS485/CAN The serial communication interfaces (RS485, RS232, and CAN) are routed to a 12-pin 3.81mm terminal, as illustrated on the figure below. Chipsee Page 11 of 20... - Page 12 Pin 4 RS232_0_RXD CPU UART0, RS232 RXD signal Pin 3 RS232_0_TXD CPU UART0, RS232 TXD signal Pin 2 System Ground Pin 1 System +5V Power Output, No more than 1A Current output Table 334 Connectivity Section Chipsee Page 12 of 20...
-
Page 13: Usb Connectors
The product has one USB Type-C connector that works as a slave by default. You can use it to establish a connection with the host PC and for downloading the system to the eMMC of CM4 module. Chipsee Page 13 of 20... -
Page 14: Lan Connectors
If you include a CM4 that has the Wi-Fi/BT module, the product will have Wi-Fi/BT feature. The enclosed (CS12720RA4050P) variant of the product also includes an SMA connector for an external WiFi/BT antenna, as illustrated in the figure below. Chipsee Page 14 of 20... -
Page 15: Camera Connector
Figure 971: Camera Connector Camera Connector Pin Definition: Pin Number Definition Description Pin 1 Power Ground Pin 2 CAM1_DN0 CAM1_DN0 Pin 3 CAM1_DP0 CAM1_DP0 Pin 4 Power Ground Pin 5 CAM1_DN1 CAM1_DN1 Pin 6 CAM1_DP1 CAM1_DP1 Chipsee Page 15 of 20... -
Page 16: Tf Card Slot
The EPC/PPC-CM4-050 industrial Pi PC features some audio peripherals. It has 1 x 3.5mm audio output jack. Also, the EPC/PPC-CM4-050 industrial Pi PC has a miniature 2W internal speaker for audio reproduction, as well as a small buzzer for alarm/notification sounds. Chipsee Page 16 of 20... -
Page 17: Boot Dip Switch
There is no need to press the button during regular operation. However, if you need to reinstall the OS, please refer to the detailed information on how to re-flash the OS from the Software Documentation. Figure 974: Boot DIP Switch Chipsee Page 17 of 20... -
Page 18: Mounting Procedure
Figure 976: Panel mounting Attention Please make sure the display is not exposed to high pressure when mounting into an enclosure. You can find detailed information about mounting in the Mount IPC Guide. Chipsee Page 18 of 20... -
Page 19: Mechanical Specifications
For CS12720RA4050P, the outer mechanical dimensions are 139 x 85 x 28mm (W x L x H). 3D Model EPC/PPC-CM4-050 3D model can be viewed in the online doc in a web browser, if you are reading from the PDF version, please visit the online doc. Chipsee Page 19 of 20... -
Page 20: Disclaimer
If you cannot find the solution you’re looking for, feel free to contact us. Please email Chipsee Technical Support at support@chipsee.com, providing all relevant information. We value your queries and suggestions and are committed to providing you with the assistance you require.
