- Page 1 VIP Series Quick Guide IP Eyeball, Dome & Fisheye VIP Series Eyeball, Dome & 360 Range Quick Guide Ver 2.0 2024-10-30...
-
Page 3: Table Of Contents
Contents Before You Begin ......................3 Packing List ......................4 Safety & Maintenance Instructions ................4 Drilling and Mounting - All Cameras ................. 5 VIP-T4MP28IRMe, VIP-T4MP28WLM-WI, ............... 6 VIP-T5MP27V135IRM, VIP-T8MP28V12IRM, ............6 VIP-T5MP28V12IRMe ....................6 VIP-T5MP28IRM, VIP-T5MP40IRM, ................ 7 VIP-T5MP28IRWLM, VIP-T5MP40IRWLM, .............. 7 VIP-T8MP28IRWLM, VIP-T8MP28IRM, .............. -
Page 4: Before You Begin
CCTV, IT and electrical wiring and products. Technical Support If you still have questions after referring to the guide, or require more information, please contact Vista Technical Support or use the QR code. Vista Technical Support +44 (0) 118 912 5125... -
Page 5: Packing List
Packing List Please contact Norbain if any items are missing or damaged and note contents will vary according to each camera model number. ➢ Camera ➢ Waterproofing items* ➢ Fixing Screws* ➢ Template* ➢ This guide Including waterproofing components such as tape and sealing grommets. Fixing screws and\or hex key according to camera model and requirement Drilling template Safety &... -
Page 6: Drilling And Mounting - All Cameras
Drilling and Mounting - All Cameras Common to all cameras is the template and drilling procedure. 1. Hold supplied template to ceiling or wall and drill 6mm to 6.5mm diameter holes to 30- mm depth. 2. Drill hole for fly lead cable to pass through (1) 3. -
Page 7: Vip-T4Mp28Irme, Vip-T4Mp28Wlm-Wi
VIP-T4MP28IRMe, VIP-T4MP28WLM-WI, VIP-T5MP27V135IRM, VIP-T8MP28V12IRM, VIP-T5MP28V12IRMe Appearance and cable identification may vary between each model. Network 1. Camera base 2. Housing 3. Mic 4. Lens 5. Power interface (12 VDC) 6. Ethernet interface 1. Loosen lock screw on camera and remove housing by turning to the position (1) shown below. -
Page 8: Vip-T5Mp28Irm, Vip-T5Mp40Irm
Note: Do not adjust camera direction by force with screw fully tightened! Loosen the screw first. Now refer to section titled 9. Power-up, Access and Set Camera Password VIP-T5MP28IRM, VIP-T5MP40IRM, VIP-T5MP28IRWLM, VIP-T5MP40IRWLM, VIP-T8MP28IRWLM, VIP-T8MP28IRM, VIP-T8MP40IRWLM Appearance and cable identification may vary between each model. Type A Type B 1. - Page 9 Type A Type B 1.Loosen locking screw and 1. Remove housing from base by remove housing by turning to aligning marks (below). position shown below (1). Install mark Install mark 2. Connect cables and screw 2. Connect cables and screw camera base to wall\ceiling.
-
Page 10: Vip-D2Mp27V135Irvrmaual
VIP-D2MP27V135IRVRMAUAL, VIP-D5MP27V135IRVRMAUAL VIP-D8MP28V12IRVRMAUAL VIP-D5MP28V12IRMe Appearance and cable identification may vary between each model. 2. Alarm input (IN, GND) Alarm output (N, P) Audio input/output/GND (excludes VIP-D5MP28V12IRMe) (excludes VIP-D5MP28V12IRMe) 3. Power interface 4. Ethernet interface (Optional) Insert Micro SD Card Insert SD card into slot for local storage function. -
Page 11: Vip-D2Mp28Irvraual, Vip-D4Mp28M-Wi
Mount transparent dome cover (below). Align the screw holes in the base, and tighten the three torx screws on the edge of the transparent dome cover to fix it. Now refer to section titled 9. Power-up, Access and Set Camera Password VIP-D2MP28IRVRAUAL, VIP-D4MP28M-WI, VIP-D4MP28IRVRMe, VIP-D5MP28IRVRAUAL Appearance and cable identification may vary between each model. - Page 12 1. Fix camera base to wall/ceiling. Pass through and connect all cables. 2. Rotate camera to position required via lens base (1) Referring to image (right), loosen locking screw (2) and adjust elevation to obtain the coverage required. Once finished, tighten locking screw (2). 3.
-
Page 13: Fisheyes
Fisheyes VIP-F5MP14IRMAUAL VIP-F12MPF18IRMAUAL 125mm (4.7”) 43.7mm (1.7”) VIP-F5MP14IRMAUAL 149mm (5.87”) 55mm (21.7”) VIP-F12MPF18IRMAUAL 1. Analogue Display 2. Audio Input 3. Alarm In 4. Power (12 VDC) 5. Audio out 6. Ethernet 7. Alarm out 8. RS 485* VIP-F5MP14IRMAUAL – rotate housing to remove VIP-F12MPF18IRMAUAL –... -
Page 14: Power-Up, Access And Set Camera Password
Installing VIP camera to a Vista VIP NVR If your Vista VIP NVR is already installed and has been set with its own STRONG admin password, you can simply “plug & play” the new VIP IP camera and select to activate it buy “pushing”... - Page 15 Refer to your relevant NVR manual for any help. This ends to procedure DOWNLOAD AND INSTALL VISTA VIZION CAMERA DISCOVERY APP Either use the QR code from your camera or visit the Vista website below and click the navigation links provided to download the Vizion Discovery App; •...
- Page 16 This completes the password activation. Continue below if you wish to change the IP address or other details of the camera. Or if satisfactory, refer to your NVR now to add the activated Vista VIP camera with the ID and password you just set.
- Page 17 IOT Password Activation and Firmware Versions Camera Model IOT Version VIP-D5MP28V12IRMe VIP-T5MP28V12IRMe DIPC-B1230.5.10.C09603.240426 (26/04/2024) VIP-D2MP27V135IRVRMAUAL VIP-D2MP28IRVRAUAL VIP-D5MP27V135IRVRMAUAL VIP-D5MP28IRVRAUAL VIP-T5MP27V135IRM GIPC-B6202.13.66.C09621.NB.240418 VIP-T5MP28IRM (18/04/2024) VIP-T5MP28IRWLM VIP-T5MP40IRM VIP-T5MP40IRWLM VIP-D8MP28V12IRVRMAUAL VIP-F5MP14IRMAUAL VIP-T8MP28IRM GIPC-B6203.12.2.C09676.NB.240418 VIP-T8MP28IRWLM (18/04/2024) VIP-T8MP28V12IRM VIP-T8MP40IRWLM...
-
Page 18: Power Requirements Per Camera Model
Power Requirements Per Camera Model CAMERA MODEL PSU Minimum 802.3af VIP-D2MP27V135IRVRMAUAL 7.5W 12VDC @ 2Amp VIP-D2MP28IRVRAUAL 5.0W 12VDC @ 1Amp VIP-D4MP28IRVRMe 7.0W 12VDC @ 2Amp VIP-D4MP28M-WI 7.0W 12VDC @ 2Amp VIP-D5MP27V135IRVRMAUAL 7.0W 12VDC @ 2Amp VIP-D5MP28IRVRAUAL 4.5W 12VDC @ 1Amp VIP-D5MP28V12IRMe 8.0W 12VDC @ 2Amp... - Page 19 No liability will be accepted by Vista for any errors or omissions in this information and reserves the right to make changes to the product and its specification from time to time without prior notice.
