Summary of Contents for Vista VVRD28V12WDR
- Page 1 Installation Manual MManualManual Set up and user manual for the VVRD28V12WDR VVRD28V12WDRIR Cameras...
- Page 3 Berkshire RG41 5TP, England. UK +44 (0) 118 912 5000 Vista Technical Helpline: +44 (0) 118 912 5125 Note: You should be at the equipment and ready with details before calling Vista Technical Support. Conventions Used in this Manual Boldface or button icons highlight command entries. The following WARNING,...
- Page 4 This apparatus is manufactured to comply with the radio interference. A Declaration of Conformity in accordance with the following EU standards has been made. The manufacturer declares that the product supplied with this document is compliant the provisions of the EMC Directive 2004/108/EC, the CE Marking Directive 93/68 EEC and all associated amendments.
- Page 5 IMPORTANT SAFEGUARDS 1. READ AND RETAIN INSTRUCTIONS Read the instruction manual before operating the equipment. Retain the manual for future reference. 2. CLEANING Turn the unit off and unplug from the power outlet before cleaning. Use a damp cloth for cleaning. Do not use harsh cleansers or aerosol cleaners. 3.
- Page 6 12. SERVICING Do not attempt to service the video monitor or equipment yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 13. DAMAGE REQUIRING SERVICE Unplug the equipment from the wall outlet and refer servicing to qualified service personnel under the Following conditions: A.
-
Page 7: Table Of Contents
TABLE OF CONTENTS INTRODUCTION --------------------------------------------------------------------------------------- 7 CONTENTS OF PACKAGE ------------------------------------------------------------------------- 8 BASIC INSTALLATION ------------------------------------------------------------------------------- 8 TACT SWITCH OPERATION / SERVICE JACK ----------------------------------------------- 9 LENS ADJUSTMENT --------------------------------------------------------------------------------- 10 OSD MENU STRUCTURE --------------------------------------------------------------------------- 11 DEAD PIXEL CORRECTION------------------------------------------------------------------------ 16 DIMENSIONS ------------------------------------------------------------------------------------------- 16 SPECIFICATIONS ------------------------------------------------------------------------------------- 17... -
Page 8: Introduction
INTRODUCTION Camera Model Features: ● 1/3” Sony IMX238 CMOS ● 120dB Wide Dynamic Range (WDR) ● True Day/Night operation ● 1000TVL colour and monochrome resolution ● 2.8-12mm (F1.4-360) 2MP varifocal IR corrected lens ● 1.0Lux (Colour) / 0.5Lux (Monochrome) / 0.01Lux (Mono & Sens-up) @ F1.4 sensitivity 1.0Lux (Colour) / 0.5Lux (Monochrome) / 0Lux (IR on) @ F1.4 sensitivity ●... -
Page 9: Contents Of Package
CONTENTS OF PACKAGE Installation of the camera must be performed by qualified service personnel in accordance with all local and national electrical and mechanical codes. Carefully remove the colour camera and its accessories from the carton and verify that they were not damaged in shipment. The content of the package includes: 1. -
Page 10: Tact Switch Operation / Service Jack
Adjusting Camera Module TACT SWITCH OPERATION The tact switch allows both navigation and changes to the OSD Menu. To enter into the OSD menu push centrally on the joystick and navigate using the up, down, left and right actions. If there is an arrow to the right of the menu function, this denotes that there is an accessible sub menu function. -
Page 11: Lens Adjustment
LENS ADJUSTMENT Zoom ring: Adjust setting from Tele (T) to Wide (W) field of View. Focus ring: Adjust lens focus from near (N) to infinity ( 2.8 to 12mm 1/2.7’’ CCD Image Size Focus ring Focal Length 2.8-12mm Zoom ring Aperture Ratio 1 : 1.4 HORIZONTAL... -
Page 12: Osd Menu Structure
OSD MENU STRUCTURE SETUP LENS EXPOSURE FOCUS ADJ FOCUS ADJ LENS BRIGHTNESS EXPOSURE SHUTTER BACKLIGHT SENS-UP DAY&NIGHT WHITE BAL RETURN RETURN RETURN SPECIAL SYSTEM EXIT DAY&NIGHT BACKLIGHT WHITE BAL MODE AUTO IR LED AUTOEXT ANTI-SAT PRESET EXTERN S/W MANUAL AGC THRES AGC MARGIN DELAY RETURN... - Page 13 FOCUS ADJ The columns from left to right assist in focusing. The higher the yellow scale on the column, the better the focus. Any green on the column shows how much the focusing could be improved by. LENS Mode: Indoor, Outdoor, Deblur Mode: Normal, Deblur EXPOSURE Brightness: 1 - 20 (increments of 1)
- Page 14 DAY & NIGHT Mode: External, Auto, Colour, B&W External: Applicable to IR model only Auto: Uses AGC to switch from colour to mono & vice versa (non-IR model) Colour: Colour only mode B&W: Monochrome only mode IR LED: Not applicable Anti-Sat: Not applicable External S/W: Not applicable AGC Thres: 1 - 20 (increments of 1), the lower number, the less AGC is...
- Page 15 IMAGE Sharpness: 0 – 10 (increments of 1) Gamma: 0.45, 0.5, 0.55, 0.6, 0.65 Pedestal: 0 – 20 (increments of 1) Colour Gain: 0 – 20 (increments of 1) Mirror: Off, on (horizontally inverts image) Flip: Off, on (vertically inverts image) Mode: Low, Middle, High SPECIAL D-Zoom: 1.0x - 8.0x (increments of 0.1)
- Page 16 Motion (4 motion detection zones) Det.Setting Sensitivity: 0 - 20 (the lower the number the lower the sensitivity) Obj. Keep LV: 0 - 60 Motion Est: 0 - 20 Signal Out: Not applicable as no alarm output Window Tone: 0 - 6 (applies level of obscurity to non motion area) Window Zone: 0 - 3 Window Use: Off, On Det H-Poz: 0 - 60 (Horizontal position of zone)
-
Page 17: Dead Pixel Correction
DEAD PIXEL CORRECTION It is perfectly normal for a camera CCD / CMOS to have what is known as ‘dead’, ‘hot’ or ‘white’ pixels, develop over time and on occasion and these can be noticeable on the viewed image. These can be masked easily, without affecting the quality of the image with the DEFECT DET function. -
Page 18: Specifications
SPECIFICATIONS Model VVRD28V12WDR Resolution 1000TVL (colour and monochrome) 1/3″ SONY IMX238 CMOS Image sensor 120dB Operation True day / night Total pixels 1305(H) x 1069(V) Effective pixels 1305(H) x 1049(V) Scanning Syst. 2:1 Interlace Scanning Freq. PAL: 15.625KHz(H) x 50Hz(V) Sync. - Page 19 Model VVRD28V12WDRIR Resolution 1000TVL (colour and monochrome) 1/3″ SONY IMX238 CMOS Image sensor 120dB Operation True day / night Total pixels 1305(H) x 1069(V) Effective pixels 1305(H) x 1049(V) Scanning Syst. 2:1 Interlace Scanning Freq. PAL: 15.625KHz(H) x 50Hz(V) Sync. system Internal 1.0Vp-p (75Ω, composite) Video output...
- Page 22 VVRD28V12WDR Manual / V1.0 / 2014-08-08 (subject to change without notice)
