Icom IC-7760 Addendum page 14

CI-V commands
Changed
The following commands are changed in, or added to
the conventional Command table.
Cmd. Sub cmd. Data
05 SET > Network
1A*
01 65 See p. 15.
01 67 See p. 15.
SET > Network > Controller Connection (via LAN) >
Audio Buffer Size
01 70 00 ~ 05
SET > Network > Controller Connection (via LAN) >
RF Deck side Settings
01 71 00/01
01 72 See p. 15.
01 73 01 ~ 30
01 74 See p. 15.
Description
Send/read the IP Address (RF Deck)
(valid after restart) setting
L Valid when the DHCP (valid after
restart) is set to OFF.
L You cannot set the same
address as "IP Address (LAN),"
"IP Address (Controller)," and
"Default Gateway."
L When "RF deck's static IP
address" (1A 05 01 71) is set to
command "01," set the address to
1A 05 01 72.
Send/read the Default Gateway
(valid after restart) setting
L Valid when the DHCP (valid after
restart) is set to OFF.
L You cannot set the same address
as "IP Address (LAN)."
L When "RF deck's static IP
address" (1A 05 01 71) is set to
command "01," set the address to
1A 05 01 74.
Send/read the Wired LAN (in Same
Segment) (valid after restart) setting
( 00=1 ms, 01=1.5 ms, 02=2 ms,
03=4 ms, 04=6 ms, 05=8 ms)
L Valid when "Connection Route"
(1A 05 03 69) is set to command
"00."
Send/read the RF deck's static IP
address setting
(00=OFF, 01=ON)
L When this item cannot be set to
"OFF," "FA" is returned.
Send/read the IP Address (RF Deck)
(valid after restart) setting
L Valid when "RF deck's static IP
address" (1A 05 01 71) is set to
command "01."
Send/read the Subnet Mask (RF
Deck) (valid after restart) setting
( 01=128.0.0.0 (1 bit) ~
30=255.255.255.252 (30 bit))
L Valid when "RF deck's static IP
address" (1A 05 01 71) is set to
command "01."
Send/read the Default Gateway (RF
Deck) (valid after restart) setting
L Valid when "RF deck's static IP
address" (1A 05 01 71) is set to
command "01."
L You cannot set the same address
as "IP Address (RF Deck)."
Cmd. Sub cmd. Data
1A* 05 SET > Network > Controller Connection (via LAN) >
Audio Buffer Size
01 75 00 ~ 04
SET > Network > Controller Connection (via LAN)
03 69 00 ~ 08
03 70 00/01
SET > Network > Controller Connection (via LAN) >
Port Forwarding Settings
03 71 See p. 15
SET > Network > Controller Connection (via LAN) >
Audio Buffer Size
03 72 0 ~ 12
03 73 0 ~ 12
*(Asterisk) Send/read data
14
V1.10
Description
Send/read the Wired LAN (from
Different Segment) (valid after
restart) setting
( 00=1.5 ms, 01=2.5 ms, 02=4 ms,
03=6 ms, 04=8 ms)
L Valid when "Connection Route"
(1A 05 03 69) is set to command
between "01" and "03."
Send/read the Connection Route
(valid after restart) setting
( 00=LAN (in Same Segment),
01=LAN (from Different Segment),
02=LAN (by on Controller Port FWD),
03=LAN (by on RF Deck Port FWD),
04=Internet (by on Both sides Port FWD),
05=Internet (by on Controller Port FWD),
06=Internet (L2 VPN in Same Segment),
07=Internet (L3 VPN from Diff Segment),
08=Internet (with Static IP Address))
Send/read The Route includes
Wireless LAN setting
(00=OFF, 01=ON)
Send/read the Connection
Destination (RF Deck WAN
Address) (valid after restart) setting
Send/read the Wired LAN (via
Internet) (valid after restart) setting
( 00=10 ms, 01=20 ms, 02=30 ms,
03=40 ms, 04=60 ms, 05=80 ms,
06=100 ms, 07=120 ms, 08=150 ms,
09=200 ms, 10=250ms, 11=300 ms,
12=400 ms)
L Valid when "Connection Route"
(1A 05 03 69) is set to command
between "04" and "08."
Send/read the Includes Wireless
LAN (valid after restart) setting
( 00=10 ms, 01=20 ms, 02=30 ms,
03=40 ms, 04=60 ms, 05=80 ms,
06=100 ms, 07=120 ms, 08=150 ms,
09=200 ms, 10=250ms, 11=300 ms,
12=400 ms)
L Valid when "The Route includes
Wireless LAN" (1A 05 03 70) is
set to command "01."
