Icom IC-7760 Addendum page 10

Set mode
Changed
DNetwork
• "Connection from Different Segment" and "Different Segment Settings" have been included in "Controller
Connection (via LAN)."
• "The Route includes Wireless LAN" is added.
• "Audio Buffer Size (via LAN)" has been included in "Audio Buffer Size."
• The Port Forwarding Settings are added.
* This setting is valid after restarting the transceiver.
» SET > Network >
MENU
Controller Connection (via LAN)
L These settings are valid after changing settings with the
controller and RF deck connected, and restarting the
transceiver.
Connection Route*
(Default: LAN (in Same Segment))
Selects the connection route between the controller
and RF deck.
L When directly connecting the controller and the RF deck,
this setting is disabled.
L See page 2 for details on each connection route.
• LAN (in Same Segment):
The controller and RF deck are in the same
segment.
Router Router
Controller Controller LAN
• LAN (from Different Segment):
The controller and RF deck are connected between
different segments .
Internet
LAN 2
Router Router
Controller Controller
• LAN (by on Controller Port FWD):
The controller and RF deck are connected between
different segments. The controller is on the LAN
side of the router with forward ports, and the RF
deck is on the WAN side.
Forwarding ports
LAN WAN
LAN 2
Router Router
Controller Controller
• LAN (by on RF Deck Port FWD):
The controller and RF deck are connected between
different segments. The controller is on the WAN
side of the router with forward ports, and the RF
deck is on the LAN side.
Internet
Forwarding ports
WAN
LAN 2
Router Router
Controller Controller
Internet
RF deck RF deck
LAN 1
RF deck RF deck
Internet
LAN 1
Router Router
RF deck RF deck
LAN
LAN 1
Router Router
RF deck RF deck
• Internet (by on Both sides Port FWD):
The controller and RF deck are connected through
the Internet, and routers are on both the controller
and RF deck side.
Dynamic DNS Dynamic DNS
Forwarding ports
LAN 2
Router Router
Controller Controller
• Internet (by on Controller Port FWD):
The controller and RF deck are connected through
the Internet, and the RF deck has a global static IP
address.
Forwarding ports
LAN Router Router
Controller Controller
* Needs a global IP address.
• Internet (L2 VPN in Same Segment):
The controller and RF deck are connected through
the Internet using the Layer 2 VPN (such as L2TP).
L2 VPN L2 VPN
Router Router
LAN
Controller Controller
• Internet (L3 VPN from Diff Segment):
The controller and RF deck are connected through
the Internet using the Layer 3 VPN (such as PPTP).
L3 VPN L3 VPN
Router Router
LAN 2
Controller Controller
• Internet (with Static IP Address):
The controller and RF deck are connected through
the Internet, and they have global static IP addresses.
Router Router
with IP unnumbered with IP unnumbered
*
Controller Controller
* Need 2 different global IP addresses for the controller and 1
global IP address for the RF deck.
10
Internet
Forwarding ports
LAN 1
Router Router
RF deck RF deck
*
Internet
RF deck RF deck
L2 VPN L2 VPN
L2 VPN
Router Router
Internet
LAN
RF deck RF deck
L3 VPN L3 VPN
L3 VPN
Router Router
Internet
LAN 1
RF deck RF deck
*
Internet RF deck RF deck
V1.10
