Specifications - HP EliteDesk 8 SFF G1i Maintenance And Service Manual

14

Specifications

This section provides specifications for your computer.
Table 14-1 Specifications
Dimensions
Height
Width
Depth
Approximate weight (standard configuration)
Temperature range
Operating
Nonoperating
Maximum altitude (unpressurized)
Operating
Nonoperating
Relative humidity (noncondensing)
Operating
Nonoperating (38.7°C max wet bulb)
Power supply
Operating voltage range
Rated voltage range
Rated line frequency
Operating line frequency
Standard efficiency
This system uses an active power factor-corrected power supply. This allows the system to pass the CE mark requirements for
*
use in the countries of the European Union. The active power factor-corrected power supply also has the added benefit of not
requiring an input-voltage range select switch.
NOTE: Operating temperature is derated 1.0°C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea
level; no direct sustained sunlight. Maximum rate of change is 10°C/hr. The upper limit might be limited
by the type and number of options installed.
122 Chapter 14 Specifications
*
Metric U.S.
100.0 mm 3.94 in
303.5 mm 11.95 in
308 mm 12.13 in
4.7 kg 10.35 lb
10°C to 35°C 50°F to 95°F
–30°C to 60°C –22°F to 140°F
5,000 m 16,404 ft
15,240 m 50,000 ft
10% to 90%
5% to 95%
90 V AC to 264 V AC
100 V AC to 240 V AC
50 Hz to 60 Hz
47 Hz to 63 Hz
550 W, 92% efficient
400 W, 92% efficient
260 W, 92% efficient
