INSTALLATION MANUAL
This is the first of two manuals
required to complete this installation.
The second manual is included with
your side bars / running boards.
Level of Difficulty
Easy
Parts List
1
Driver / left
side bar / running board
1
Passenger / right
side bar / running board
4
VersaTrac
mounting
™
bracket, universal
2
Bolt plate, M6
2
Flat washer, M6
2
Lock washer, M6
2
Hex nut, M6
28 Hex bolt, M8 - 1.25 x 25mm
28 Flat washer, M8
28 Lock washer, M8
16
Hex nut, M8
*Running boards sold separately
Tools Required
Ratchet
Socket, 10mm
Torque wrench
Socket, 13mm
Level
--
Torque Specifications
M6 bolt
3 ft-lbs.
M8 bolt
7 ft-lbs.
Use above torque setting unless otherwise noted
ARIESAUTOMOTIVE.COM
Product Photo
NOTICE
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
To help prevent damage to the product or vehicle, refer to the specified
torque specifications when securing hardware during the installation process.
Maintenance
To protect the product, wax after installing. Regular waxing is recommended
to add a protective layer over the finish. Do not use any type of polish or wax
that may contain abrasives that could damage the finish.
For polished, gloss and other smooth finishes,
polish may be used to clear small scratches and scuffs on the finish.
Mild automotive detergent may be used to clean the product. Do not use dish detergent, abrasive
cleaners, abrasive pads, wire brushes or other similar products that may damage the finish.
Product Registration and Warranty
CURT Group stands behind our products with industry-leading warranties.
Provide feedback and help us to improve our products by registering your purchase at:
warranty.curtgroup.com/surveys
•
NEED ASSISTANCE?
•
877.287.8634
Front
•
2055130-INS-RC
•
PAGE 1
2055130
Rear
Advertisement
Related Manuals for Curt Group Aries 2055130
Summary of Contents for Curt Group Aries 2055130
- Page 1 Socket, 10mm Torque wrench Socket, 13mm Product Registration and Warranty Level CURT Group stands behind our products with industry-leading warranties. Provide feedback and help us to improve our products by registering your purchase at: warranty.curtgroup.com/surveys Torque Specifications M6 bolt 3 ft-lbs.
- Page 2 Step 1 Starting on the driver side, locate the four mounting tabs along the bottom edge of the vehicle. Step 2 Starting at the front driver-side mounting location, locate the threaded hole on the inside of the body panel. Place a bracket onto the vehicle and secure with two M8 hex bolts, lock washers and flat washers.
