INSTALLATION MANUAL
Level of Difficulty
Easy
This is the first of two manuals
required to complete this installation.
The second manual is included with
your running boards / side steps.
Parts List
6
VersaTrac
mounting bracket, universal
™
6
Serrated flange nut, M8
12
Hex bolt, M8 (S)
12
Flat washer, M8 (S)
12
Lock washer, M8 (S)
12
Hex bolt, M8 (B)
12
Flat washer, M8 (B)
12
Lock washer, M8 (B)
12
Hex nut, M8 (B)
(S) = Silver hardware, (B) = Black hardware
Running boards / side steps sold separately
Tools Required
Ratchet
Level
Torque wrench
Socket set
Flathead screwdriver --
Torque Specifications
M6 bolt
3 ft-lbs.
M8 bolt
7 ft-lbs.
M10 bolt
16 ft-lbs.
M12 bolt
28 ft-lbs.
1/4" bolt
3 ft-lbs.
5/16" bolt
7 ft-lbs.
3/8" bolt
16 ft-lbs.
7/16" bolt
20 ft-lbs.
1/2" bolt
28 ft-lbs.
Use above torque setting unless otherwise noted
ARIESAUTOMOTIVE.COM
Product Photo
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
Mild automotive detergent may be used to clean the product. Do not use dish detergent, abrasive
cleaners, abrasive pads, wire brushes or other similar products that may damage the finish.
Refer to the table to the left when securing hardware during the
installation process to help prevent damage to the product or vehicle.
Product Registration
CURT Group stands behind our products with industry leading warranties.
You can help us continue to improve our product line and help us understand
your needs by registering your purchase by visiting:
warranty.curtgroup.com/surveys
At CURT Group, customer is king. We value your feedback and we use that information to make
improvements on our products. Please, take a minute and let us know how we are doing.
•
NEED ASSISTANCE?
•
844.278.4357
•
2055142-INS-RD
•
PAGE 1
2055142
Front
Rear
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Curt Group Aries 2055142
Summary of Contents for Curt Group Aries 2055142
- Page 1 Torque Specifications At CURT Group, customer is king. We value your feedback and we use that information to make improvements on our products. Please, take a minute and let us know how we are doing. M6 bolt 3 ft-lbs.
- Page 2 Step 1 Starting on the driver side, locate the four mounting tabs along the bottom edge of the vehicle body. This installation will use the first, second and fourth mounting tabs. Step 2 Starting at the front driver-side mounting location, use a flathead screwdriver to remove the plastic plugs, exposing the threaded inserts on the rocker panel.
- Page 3 1/2" bolt 28 ft-lbs. At CURT Group, customer is king. We value your feedback and we use that information to make Use above torque setting unless otherwise noted improvements on our products. Please, take a minute and let us know how we are doing.
- Page 4 Step 1 Place the mounting plates into the track on the running board. Carefully place the running board onto the mounting brackets. Slide the mounting plates along the track to align with the mounting brackets on the vehicle. Secure the running board to the mounting brackets using two M8 hex bolts, two lock washers and two flat washers.
