Hand Crimp Tool for TPX50-50 Gen2 Receptacle 0.35 mm M Grip
Order Number
213309-8600
FEATURES
A full cycle ratcheting hand tool ensures complete crimps
Ergonomic soft grip handles for comfortable crimping
Right- and left-handed applications
Easy handling due to outstanding force ratio
A precision user-friendly terminal locator with wire stop that holds terminals in the proper
crimping position
Tooling can be installed in the 63816-1950 Power Crimp Adapter, which is installed into the 63816-
0270 (110 V) or 63816-0280 (220 V) Battery Powered Tools and the 63816-1900 Electric Crimp
Machine
This tool is RoHS compliant; however, RoHS compliance is not required
SCOPE
Products: TPX50-50 Gen2 Receptacle 0.35 mm M Grip intended for use with 7 or 19 count
stranded 0.35mm² FLRX91-A XLPO wire.
Terminal Series
No.
201691
(1) Customer to cut off terminal from reel: 0.20mm (.008") maximum cut-off tab.
Doc. No: 213309-8600
Revision: A
Application Tooling Specification
Wire Size
Terminal Order
No. (1)
mm
201691-4131
0.35mm²
201691-4171
Release Date: 04-19-23
Revision Date: 04-19-23
Insulation Diameter
Wire Type
2
mm
FLR91X-A
1.20-1.40
XLPO
UNCONTROLLED COPY
Strip Length
In.
mm
In.
.047-.055
3.50
0.138
Page 1 of 8
Type 4A
Advertisement
Table of Contents
Related Manuals for molex 213309-8600
Summary of Contents for molex 213309-8600
- Page 1 FLR91X-A 201691-4131 201691 0.35mm² 1.20-1.40 .047-.055 3.50 0.138 XLPO 201691-4171 (1) Customer to cut off terminal from reel: 0.20mm (.008”) maximum cut-off tab. Doc. No: 213309-8600 Release Date: 04-19-23 UNCONTROLLED COPY Page 1 of 8 Revision: A Revision Date: 04-19-23...
-
Page 2: Definition Of Terms
0.08mm (.003”) below datum D-0.14mm (.006”) above datum D 16. Insulation Grip 0.10mm (.004”) MAX; True position with respect to datum E Straightness ♦ See Additional Definition of Terms section. ♦ Doc. No: 213309-8600 Release Date: 04-19-23 UNCONTROLLED COPY Page 2 of 8 Revision: A Revision Date: 04-19-23... - Page 3 4. Molex does not repair hand tools. See warranty on page 6. The replacement parts listed are the only parts available for repair. If the handles or crimp tooling become damaged or worn, a new tool must be purchased.
-
Page 4: Operation
Note: The tamper-proof ratchet action will not release the tool until it has been fully closed. Note: To maintain good brush control and a consistent bell mouth, the crimping instructions must be followed. Doc. No: 213309-8600 Release Date: 04-19-23 UNCONTROLLED COPY... -
Page 5: Maintenance
5. When the tool is not in use, keep the handles closed to prevent objects from becoming lodged in the crimping dies, and store the tool in a clean, dry area. Doc. No: 213309-8600 Release Date: 04-19-23 UNCONTROLLED COPY... - Page 6 All vital components are long-life tested. All tools are warranted to be free of manufacturing defects for a period of 30 days. Should such a defect occur, Molex will repair or exchange the tool free of charge. This repair or exchange will not be applicable to altered, misused or damaged tools.
- Page 7 Disconnect the power by unplugging, or turn off the actuator from its power source. CAUTION: Keep fingers away from the crimping area when operating this tool. It may cause severe injury. CAUTION: Wear safety glasses when operating or servicing this tool. Doc. No: 213309-8600 Release Date: 04-19-23 UNCONTROLLED COPY Page 7 of 8...
-
Page 8: Parts List
Application Tooling Support E-Mail: toolingsupport@molex.com Website: www.molex.com/applicationtooling Molex is a registered trademark of Molex, LLC in the United States of America and may be registered in other countries; all other trademarks listed herein belong to their respective owners. Doc. No: 213309-8600...
