- Page 1 T42C Owner Manual For Motorized Treadmill T906 Please read all precautions and instructions in this manual before in detail before using this equipment. Save this manual for future reference.
-
Page 2: Security Considerations
Security considerations 1、Electric treadmill in a clean and smooth place, do not put electric treadmill on the thick carpet, lest affect the circulation of air in the lower part of the electric treadmill. Also do not put electric treadmill near water or outdoor use, pay attention to moisture-proof. 2、After the electric treadmill is fully installed and the motor protection cover. - Page 3 Attention 1.In order to avoid accidental injury, you must pay attention to the following: please warm up before exercise Any strenuous exercise can only start after 40 minutes after meals Before using the treadmill, check whether the power supply is loaded and the safety lock is effective.
- Page 4 1、Two or more people are not allowed to use the treadmill at the same time. 2、Under the guidance of the doctor , please use. 3、The heartbeat monitoring system is for reference only and cannot be used as medicine.Excessive Exercise can cause serious injury or death.If you feel dizzy,stop exercising immediately.
-
Page 5: Installation Tools
Installation tools: 5 # Hex key 5mm 1pcs 6 # Hex key 6mm 1pcs Cross open end wrench 1pcs Note Do not plug in the power until the installation is complete STEP 1：Remove the following materials from the box and place the main frame on the ground, cutting off the packaging tape. - Page 6 STEP 4:First, insert the outgoing line (78) at the D of the meter core into the outgoing line (79) at the F of the Electric watch. After the meter core and the Electric watch are aligned to the hole position, use the tool Hex key (5 #) (95) to lock the meter core (6) on the Electric watch, and use the hexagonal socket pan head bolt M8 * 20 (25) for the screw, as shown in the left figure.
-
Page 7: Grounding Instructions
STEP 7: With one hand at position A, kick the air pressure rod with your foot, and press down slightly with the hand at position A until it reaches the end of the armrest. After the machine releases its grip, it will automatically lower NOTE: For your safety and comfort,please check if all screws are fastened Congratulation! A brand new motorized treadmill has been successful assembled! -
Page 8: Electronic Operation
Electronic operation Ⅰ Overview Functions carried by this electronic watch: - Up and down function - MP3 interface play function - USB interface playback function - Hand-held heartbeat function Terminology conventions used in the manual: Treadmill parameters: Speed value, Slope value Exercise parameters: "Distance"... - Page 9 Ⅱ .Parameter Descriptio .Motion parameters under various motion modes: ·Minimum displayed speed 1 km/h ·Maximum display speed of 20 km/h Maximum exercise time in time mode: 99 minutes ·Minimum exercise time in time mode: 8 minutes ·Maximum movement distance in distance mode: 99 kilometers ·Minimum movement distance in distance mode: 1 kilometer ·Maximum calories burned in calorie mode: 990 calories ·Minimum calories burned in calorie mode: 20 calories...
- Page 10 2. After entering the automatic program setting, continue to operate this button to enter the custom progra 3. After entering the custom program settings, continue to operate this button to enter the body fat test settings state 4. Operation process: Automatic program - Custom program - Body fat test - Return to initial state ·Mode key - Function description: Countdown mode selection Operating instructions:...
- Page 11 If the exercise time exceeds 99:59 minutes, the system will not shut down and the time will start counting from scratch B. Countdown mode function 1. Enter time countdown mode: In the initial standby mode, press the mode key to select time countdown mode.
- Page 12 backwards according to the set running time. The distance and calorie windows start counting positively from zero. Press the speed adjustment button to adjust the size of the running speed value, and press the up and down adjustment button to adjust the size of the running slope value, When the program runs to the next section, the speed and slope values are automatically adjusted to the internal fixed values of the next section.
- Page 13 Body fat test: After the setting is completed, enter the fifth item of body fat test, and the initia display is "---". At this time, hold both hands onto the heartbeat test steel plate for about 5 seconds, and the index of body fat test will be displayed.
- Page 14 USB Functio Ⅻ、 When the USB stick is inserted after power on (when the MP3 hole is not inserted into the MP3 device), the Electric watch can play music in MP3 format in the USB stick. The latest 60 built-in program data table 20 paragraphs Time Set the set time/20 time periods as the running time of the upper and lower time periods Program...
- Page 15 INCLIN SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE 10 8 SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE 12 8 SPEED INCLINE SPEED...
- Page 16 SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED 10 5 INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE...
- Page 17 Treadmill AC system error message prompt descriptio Er01 : indicates that the electronic meter and the electronic control communication abnormal phenomenon prompt Er01 Common The communication line of the Electric Please reconnect the communication cable problem-solving watch is not well connected, broken, and methods in poor contact The electronic meter has no signal output...
-
Page 18: Safety Exercise
E07：The electronic meter security lock is not place E07 Common Safety magnet escape Please put the safety lock on the designated problem-solving position of the Electric watch methods Electric watch safety lock system failure Replace the Electric watch for maintenance Safety exercise Guide to getting started with sports Preparation：... - Page 19 The method of consuming heat - this method will truly consume the heat. Warm up for 5 minutes at a speed of 4 to 4.8 kilometers per hour, then increase the speed by 0.3 kilometers per hour every 2 minutes until you find it challenging to continue exercising for 45 minutes at a certain speed.
- Page 20 Exercise warm-up Before exercising, it's best to do stretching exercises first. Warm muscles are easier to stretch, so warm up for 5-10 minutes first. Then stop and do the stretching exercise as follows - do 5 times, each leg for 10 seconds or more at a time, and do it again after the exercise is over. 1.
-
Page 21: Running Belt Adjustment
Warning: Before moving the motor protective cover, be sure to unplug the power plug of the electric Treadmill. Open the motor protective cover at least once a year to vacuum and clean the motor. Use running belts and electric running special lubricating oil The running board of the electric Treadmill and the running belt have been per coated with lubricating oil. - Page 22 Running belt centered ： Place the electric Treadmill on the flat ground. Run the electric Treadmill at a speed of about 6-8 km/h and observe the deviation of the running belt If the running belt is to the right, pull out the safety lock and power switch, rotate the right adjusting bolt 1/4 circle clockwise, insert the power switch and safety lock, make the Treadmill run, and observe the deviation of the running belt.
-
Page 23: Explosive View
Explosive View... - Page 24 Explosion details Serial Name Remarks Name Remarks number base Core panel Movement Main frame back cover Movement Left pillar frame Armrest Right pillar cover Armrest Watch stand undercover Core fixing plate Running belt Running Lifting frame board Running board cushion Sidebar tube Semi-circular...
- Page 25 Annular wire Inner hexagonal bolt M8*45 protection plug Inner hexagonal bolt M8*40 T-shaped tee Safety lock Inner hexagonal bolt M8*25 assembly Safety lock Inner hexagonal bolt M8*20 sensor Electric Outer hexagonal bolt M8*35 watch Hexagon bolt with M8*65 Film button cylindrical head Hexagon bolt with M8*12...
- Page 26 Silicon oil Flat gasket ￠10 bottle Flat gasket Magnetic ring ￠8 Inner Standard spring pad hexagonal ￠8 wrench Inner Arc spacers hexagonal ￠8 wrench Cross open Motor upper cover end wrench Motor lower cover inductance Optional Left rear tail cap filter Optional Right rear tailgate...
