- Page 1 T42C Owner Manual For Motorized Treadmill T 99 Please read all precautions and instructions in this manual before in detail before using this equipment. Save this manual for future reference.
-
Page 2: Table Of Contents
CONTENTS Contents Safety Caution Assembly instruction Operation guide 7-11 How to fold and move Suggested stretches 13-14 Maintenance 15-16 Exploded drawing Part list Trouble shooting guides 19-20... -
Page 3: Safety Caution
SAFETY CAUTIONS When using this product, basic precautions should always be followed, including the following: Please read the instruction carefully before starting to use this product. Danger – To reduce the risk of electric shock： Always unplug this product from the electrical outlet immediately after using and before cleaning. - Page 4 SAFETY CAUTIONS GROUNDING INSTRUCTIONS The products must be grounded first. If malfunction or breakdown occurs, grounding will provide a path of least resistance for electric current to reduce the risk of electric shock. The product is equipped with a cord having an equipment-grounding conductor and a grounding plug.
-
Page 5: Assembly Instruction
ASSEMBLY INSTRUCTIONS OPEN THE BOX YOU CAN FIND THE ALL PARTS AS BELOW. - Page 6 ASSEMBLY INSTRUCTIONS STEP 1 1. Open the packing carton, put the main frame on the level ground. STEP 2 1. Lift up the left and right upright (2) with the computer until not move show as the picture. At the same time, be careful not to damage the cables inside left and right upright (2)。...
- Page 7 ASSEMBLY INSTRUCTIONS STEP 3 1. Fasten the right and left base cover (9) onto base (1) with M4*15 screw (10). STEP 4 NOTE: For your safety and comfort, please check if all screws are fastened Congratulation! A brand new motorized treadmill has been successful assembled!
-
Page 8: Operation Guide
OPERATION GUIDE GENERAL SAFETY TIPS A. Practice mounting and dismounting your treadmill before beginning your workout. B. Attach the Safety Key to the Computer (the treadmill will not operate without the Safety Key). Clip the other end of the Safety Key to your clothing before exercising to ensure the treadmill will stop if the user accidentally walks off the Treadmill. - Page 9 window will display H-1, H-2, H-3 during setting of manual program. When the safety key is not on position, the entire LCD screen will display E07 only. OPERATION GUIDE GETTING STARTED NOTES: . Check to make sure nothing is on or will hinder the movement of the treadmill. 2.
- Page 10 need to continue, press the START button to begin belt movement after a three second count-down. OPERATION GUIDE Attach the Safety key to wake display up; the treadmill then will be on start/ready STEP 1: status. Press MODE button, the manual program will be selected, SPEED window will STEP 2: display H-1, TIME window will blink in and display 30:00, press FAST and SLOW button to set count-down TIME from 10:00 minutes to 99:00 minutes.
- Page 11 to shut down the computer, the SPEED window will show E 07 after you pull off the safety. OPERATION GUIDE PRESET PROGRAM CHART Each program divided moving time into 10 segments; the speed on each segments have been pre-set in the factory. Program Speed Speed...
- Page 12 OPERATION GUIDE BODY FAT SCALE This function is to estimate your body fat according to the basic information of you body condition. This estimate is not exact and persons with medical conditions and/or a specific need for accurate body fat value should not rely on the estimations provided. STEP 1: Attach the Safety key to wake display up;...
-
Page 13: How To Fold And Move
HOW TO FOLD AND MOVE HOW TO FOLD THE TREADMILL Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be permanently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20kg) in order to raise, lower, or move the treadmill. -
Page 14: Suggested Stretches
SUGGESTED STRETCHES A successful exercise program consists of a warm-up, aerobic exercise, and a cool-down. Do the entire program at least two and preferably three times a week, resting for a day between workouts. After several months, you can increase your workouts to four or five times per week. - Page 15 SUGGESTED STRETCHES 4. Shoulder Lift Lift your right shoulder up toward your ear for one count. Then lift your left shoulder up for one count as you lower your right shoulder. 5. Toe Touch Slowly bend forward from your waist, letting your back and Shoulders relax as you stretch toward your toes.
-
Page 16: Maintenance
MAINTENANCE WARNING! Before performing any maintenance to your treadmill, always unplug the power cord from the surge protector. CLEANING: Routine cleaning of your TREADMILL will extend the life of your treadmill. WARNING! To prevent electrical shock, be sure the power to the treadmill is OFF and the unit is unplugged from the wall electrical outlet before attempting any cleaning or maintenance. - Page 17 MAINTENANCE Running belt tension adjustment The treadmill has been adjusted and passed QC inspection before leaving the factory. If there is phenomenon of bias running of the belt ,the possible reasons might be: A. The frame is not stably laid B.
-
Page 18: Exploded Drawing
EXPLODED DRAWING... -
Page 19: Part List
PART LIST Description Description Base Handrail button kit Left Main frame Handrail button kit Right Left upright Air cylinder Right upright Manual incline lock pin Handrail rack Wrench Foot rail fastener Console Lubricant oil bottle Motor cover Foot rail cushion Foot rail Bolt M10x25 Rear end cap Left... -
Page 20: Trouble Shooting Guides
TROUBLE SHOOTING ERROR CODE POSSIBLE CAUSES CORRECTION Check whether the speed sensor is installed well, whether the Defection on speed sensor. sensor is broken, and whether the distance between sensor and roller is in 3-5MM. Overload or over voltage Switch off the power and switch protected. - Page 21 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSES CORRECTION Treadmill will not 1. Not plugged in. 1. Tighten into suitable outlet. start 2. Safety key not attached 2. Insert safety pull pin. correctly. 3. Reset circuit breaker. 3. Treadmill circuit breaker 4. Turn on On/Off switch. tripped.
