Heating mode
8 0С Cooling mode
(optional)
SMART mode
HI - NANO mode
(optional)
Battery charge level
TURBO mode
I Feel mode
Quiet mode
Cleaning (optional)
RC BUTTON USE
1. ON/OFF BUTTON
• To turn the appliance on/off, press button (1). When the appliance
is operating, the operation indicator on the indoor unit will be on.
• If the air conditioner shuts down because of protective appliance
activation you can resume operation after 3 minutes.
• After connecting to power supply the air conditioner will not
start up until after 20 seconds.
• If the air conditioner shuts down because of protective appliance
activation, press the ON/OFF button to turn it on.
• When the air conditioner is disconnected from power supply, all
timer settings are reset.
2. TEMPERATURE INCREASE/DECREASE BUTTONS
Use buttons (2) to set the required air supply temperature. Each
press of the button increases /decreases the value by 1 ⁰C.
Optimum settings:
• "Cooling", "Heating": 16 to 30 ⁰C;
• "Drying": -7 to 7 ⁰С;
• "Ventilation": not adjustable.
NOTE: to change the unit of measurement ⁰C/⁰F, press and hold the
"РЕЖИМ" and buttons simultaneously for 3 seconds.
3. TURBO MODE BUTTON
Pressing the button activates the TURBO mode. When activated
in the "Cooling", "Drying" or "Ventilation" mode, the air flow
temperature is set to 160C. When activated in the "Heating" mode,
the air flow temperature is set to 30 ⁰C. To cancel the mode, press
any of the buttons: "ТУРБО", "РЕЖИМ", "СКОРОСТЬ", "ON/OFF", "ТИ-
ХИЙ", "СОН". The mode indicator on the display will go off.
Lock
Very low fan speed
Low fan speed
Medium fan speed
High fan speed
Very high fan speed
Auto fan speed
Power saving mode
(optional)
Output (optional)
Click / Timer
Temperature
4. FAN SPEED SETTING BUTTON
Each time the button is pressed the air conditioner fan speed will
be changed in the following sequence: "Automatic" / "Very High" /
"High" / "Medium" / "Low" / "Very Low".
The corresponding indication appears on the remote control
display:
5. SMART MODE BUTTON
In SMART mode, the air conditioner system automatically adjusts
the operating mode, air flow temperature, fan speed, air flow
direction, etc., according to the room temperature for a more
comfortable user experience. When the SMART mode is active, you
can independently adjust the blowing speed and position of the
flaps. To exit the mode, press the "РЕЖИМ" button (6).
NOTES:
• The function not accessible in TURBO mode.
• The Power saving mode cannot be activated.
6. MODE SELECTION BUTTON
Each time the button is pressed the operating mode of the air
conditioner change in the following sequence: "Cooling" / "Drying"
/ "Ventilation" / "Heating".
The display of the remote control shows the relevant mode:
NOTE: When the "Heating" mode is activated, warm air will begin to
flow after 2-5 minutes. When operating in the "Heating" mode, the
defrosting mode of the outdoor unit will be activated from time to
time. The process takes from 2 to 5 minutes. During defrosting, the
indoor unit fans stop running.
7. "I FEEL" MODE BUTTON
In this mode the sensor built into the remote control reads the
information about the temperature in the room. Thus, during
operation of the appliance, the air flow temperature and blowing
speed will be set automatically.
To activate the function, press the iFEEL button (7), the
corresponding indicator will light up on the remote control display.
To disable the function, press the button again. The indicator will
go out.
NOTE: For saving electric power it is recommended to disable this
feature.
8. SLEEP MODE BUTTON
The Sleep function provides a more comfortable sleep environment.
The appliance automatically sets the fan speed to low and turns off
after 8 hours of operation.
This function can be activated in the "Cooling", "Heating", "Drying"
modes. Each time the button is pressed the operating mode will
change as follows: "Sleep 1", "Sleep 2", "Sleep 3", "Sleep 4".
The relevant indication will appear on the remote control display:
