2N IP Safety User Manual page 27

Connector
X1 Speaker
X4 Camera module
X5 Button 1
SW1 Reset button (PCB version 555v3 and higher)
X6 Configuration jumpers
X7 Induction loop output Connector type JST SHR-02V-S
X8 Extending module (RFID card reader or additional switch)
X10 Buttons 1 through 4
X11 LAN connection
X12 Servicing connector
X13 Keypad module
X15 Left-hand microphone
X16 Right-hand microphone
X17 Relay NO and NC contacts max. 30 V / 1 A AC/DC. Used for connection of non-critical
devices only (lights, e.g.).
X18 Switched output 12 V, up to 600 mA
X19 12 V / 1 A DC power input
LED1/2 System status indicators are displayed
