Maintenance
3. Drain oil into a suitable container.
4. Install oil drain plug onto end of oil drain hose.
5. Install oil drain hose into holding clamp.
6. See Figure 5-8. Turn oil filter (C) counterclockwise
to remove from oil filter adapter.
NOTE: Dispose of used oil and oil filter in accord-
ance with local, state, or national laws.
Figure 5-8.
E
Figure 5-8. Engine Oil and Air Cleaner Maintenance
C
D
E
7. Apply a light coat of clean engine oil to gasket of
new oil filter.
8. Install oil filter by hand until gasket just contacts oil
filter adapter. Tighten oil filter an additional three-
quarters to one full turn.
9. Remove oil fill cap and fill engine with the recom-
mended quantity and type of oil. See
Recommendations. Crankcase oil capacity is
listed below:
Model
100 kW / 130
kW / 150 kW
10. Install oil fill cap.
11. Install negative (-) battery cable (black) onto nega-
tive (-) battery terminal.
12. Pull up rubber flap covering fuse holder and install
7.5 amp fuse.
13. Press MANUAL on control panel to start engine.
34
D
C
012626
Oil filter
Air cleaner
Oil fill cap
Engine Oil
System
Engine
Capacity
10 qts (9.5 L)
9.0 L
14. Allow engine to run for one minute. Inspect for
leaks while engine is running.
15. Press OFF on control panel. A red LED illuminates
to verify system is OFF.
16. Wait 10 minutes for engine to cool and to allow oil
to drain back to oil pan.
17. Check oil level and add oil as necessary. See
Checking Lubricating Oil Level and Drain
18. Install oil fill cap.
Checking Battery Condition/Fluid Level
Checking Condition and Cleaning
1. Verify top of battery is clean and dry. Dirt and elec-
trolyte on top of the battery can cause battery to
self-discharge. Clean battery top with a solution of
baking soda (sodium bicarbonate) and water (5
teaspoons baking soda per quart or liter of water).
When solution stops bubbling, rinse off the battery
with clean water.
2. Clean cable clamps and battery terminals using a
wire brush or sandpaper to remove any oxidation.
3. Inspect battery screws, clamps, and cables for
breakage, loose connections, and corrosion. Tight-
en and clean as necessary.
4. Inspect battery posts for melting or damage caused
by over tightening.
5. Inspect battery for discoloration, raised top, or a
warped or distorted case, which might indicate bat-
tery has been frozen, overheated, or overcharged.
6. Inspect battery case for cracks or leaks.
7. Check battery fluid level of unsealed batteries. See
Checking Fluid Level.
8. Verify battery state of charge. See
tery State of Charge.
9. Replace battery
Replacement.
Checking Fluid Level
Check the fluid level of unsealed batteries. If necessary,
fill with distilled water only. DO NOT use tap water.
Verifying Battery State of Charge
Verify the battery state of charge using a digital multi-
meter (DMM). Charge and retest if state of charge is be-
low manufacturer's recommendations. Replace battery if
necessary.
Spark-Ignited Stationary Generators Owner's Manual
Hose.
Verifying Bat-
if necessary. See Battery
